SADEV Glass Canopies from BM Architectural
Verified by manufacturer 14 hours ago
Light
Light
Glass canopies from the SADEV® Classic range.
Application
Glass canopies for a range of applications.
Description
Glass canopies from the SADEV® Classic range.
Plazza:
- Glass canopy with several fixing points.
- Easy installation.
- Multiple glazing from 13.52 to 25.52 mm.
- Available as a kit.
- Evolutive according to the glass panels.
Light:
- Glass design canopy for house front door.
- Good value for money: competitive.
- Only one reference to order.
- Glass thickness is 5.5 or 6.6 mm.
- Full kit available.
Arcade:
- Four to six point glass canopy.
- Easy and quick to install.
- Available in kit for glass thickness from 13.52 to 25.52 mm.
- Tailor-made canopy can be designed to project requirements.
General information
Color | Clear Silver |
Finish | Smooth |
Material | Glass Stainless steel |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Uniclass | |
CAWS | B91/475 Glass L10/59 Solar shading systems L10/680 Solar shading systems B91/330 Canopy |
SKU Code | 131LIGHT |
Specification data - Open-sided shelters
Classification data | |
Shelter description | Glass design canopy for house front door. |
Dimensions | |
Plan size | As Roof covering. |
Frame | |
Material | Grade 316 stainless steel. |
Finish | Manufacturer's standard. |
Colour | Silver. |
Roof covering | Glazed, 5.5–6.5 mm thick. Guidance for specification option: Insert requirements.
Manufacturer guidanceConsult manufacturer's literature for fixing point locations. |
Accessories | Not required. |
Fixings | Bottom brackets, top brackets, gussets and tension rods required. |
Point fixings | Four. |
Sustainability data
Material | Glass Stainless steel |
