SecuRex2® SR2 (B3) 358 Security Rated Prison Mesh LPS1175 - Fencing
Verified by manufacturer 4 days ago
LPS1175 B3 (SR2) security-rated mesh fencing system.
Application
Suitable for schools, warehouses, utilities, prisons and infrastructure sites.
Description
SecuRex2 is an SR2-rated mesh fencing that offers a lightweight yet maximum-security solution for perimeter fencing. Using a single panel, it is easy to manoeuvre and install on site. With 20 M6 fixings per post, the chances of intrusion are highly mitigated.
Features and benefits:
- Utilises 5.5 mm horizontal and vertical wires to create an aperture of 11.5 x 76.2 mm.
- Single panel weight: 115 kg.
- Approximately 20 M6 fixings per post.
- Variable internal angle corner enables full system security even on awkward perimeter boundaries.
General information
Color | Green Black Other |
Finish | Powder-coated |
Material | Steel |
Shape | Rectangle |
Length | Bespoke |
Width | 2520 mm Guidance for specification option: Panel width. |
Height | 2433 mm |
Warranty description | Ten year |
Uniclass | |
CAWS | Q40/28 Open mesh steel panel security fencing Q40/126 Open mesh steel panel security fencing Q40/430 Proprietary fencing Q40/30 Proprietary fencing |
Specification data - Metal mesh panel fencing systems
Classification data | |
Standard | To LPS 1175, SR2 (B3). |
Posts | 80 x 60 x 3 mm rectangular hollow section (RHS). Manufacturer guidance500–3000 mm post centres. |
Panels | 2.52 m wide steel mesh panels comprising 5.5 mm diameter wires. Mesh size: 76.2 x 11.5 mm. |
System accessories | Manufacturer guidanceConsult manufacturer and insert requirements. |
SecurityRating | To LPS 1175, Security Rating B3 (SR2). |
Finish/ Colour | Polyester powder-coated, green. Polyester powder-coated, black. Polyester powder-coated, bespoke. Guidance for specification option: Consult manufacturer and insert requriements. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Turkey |
Country of product manufacture | France |
Material | Steel |
| Carbon dioxide equivalent | |
Carbon dioxide equivalent, as defined in BS EN 15804 Self-declared | |
Stage Normalised unit (kg CO₂ eq/kg) Declared unit (kg CO₂ eq/unit) Stage:A1–A3 ('Production stage') Normalised unit : Declared unit : 0.16 | |
Recyclability | 95% |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 80 % |
Expected Life | Ten year |
