SentryGlas® - Laminated glass interlayer
Verified by manufacturer 28 days ago
Ionoplast interlayer
Application
- SentryGlas® is the best choice, with over 20 years of outdoor exposure, for open edge applications that require the very best edge durability and optics.
- SentryGlas® is recommended for applications that require the highest structural performance over a broad range of temperatures and loads
- SentryGlas® is best for Level E (essential facility) protection
- SentryGlas® recommended for large glass, high wind loads, or dry glaze systems.
Description
Ionoplast interlayer for use in laminated safety glass.Open edge design thanks to SentryGlas®.
High adhesion: Specially designed for laminated safety glass, made with heat strengthened or tempered glass. It reduces the risk of edge delamination. Superior post breakage and structural properties.
- SentryGlas® is specified by the US State Department for higher bomb blast requirements of US Embassies.
- SentryGlas®, SentryGlas® Xtra™ and Trosifol® PVB pass large missile impact test and have obtained Miami Dade County Product Control Notice of Acceptance (NOA).
- Window systems using SentryGlas® and Trosifol® Spallshield® CPET are capable of passing FEMA 361 EF5 tornado test.
- SentryGlas®, Trosifol® PVB and Trosifol® Spallshield® CPET interlayer comply with global security glazing standards.
- SentryGlas® certified by the US Department of State for FE (forced entry) BR (bullet resistance).
General information
Color | Clear |
Material | Ionoplast |
Length | 5000 mm 25000 mm |
Width | 1050 mm 1150 mm 1220 mm 1300 mm 1530 mm |
Height | 0.76 mm 0.89 mm |
Uniclass | |
CAWS | L40/530 Internal tape glazing L40/515 Fire-resistant channel glazing – plastics/ elastomeric channel L40/510 Fire-resistant channel glazing – solid section channel L40/505 Fire-resistant tape/ Strip glazing L40/490 Single-sided gasket glazing L40/470 Zipper gasket glazing L40/450 Single glazing into grooves – sealant capping L40/430 Single glazing into grooves – non-setting compound L40/410 Single glazing into grooves – extruded rubber/ PVC sections L40/90 Internal tape glazing L40/80 Fire-resistant channel glazing – plastics/ elastomeric channel L40/75 Fire-resistant channel glazing – solid section channel L40/65 Fire-resistant tape/ Strip glazing L40/50 Bead-fixed single glazing L40/40 Putty-fronted single glazing L40/250 Bead-fixed single glazing – tape and sealant L40/230 Bead-fixed single glazing – non-setting compound L40/350 Bead-fixed single glazing – curing compound and trim L40/330 Bead-fixed single glazing – capping L40/310 Bead-fixed single glazing – tape, sealant and trim L40/260 Bead-fixed single glazing – extruded gasket L40/210 Putty-fronted single glazing |
Specification data - Ionomer sheets
Ionomer type | Safety. |
Thickness | 0.76 mm.0.89 mm.1.52 mm.2.28 mm. |
SolarAbsorption | 19–21%, depending on film thickness. |
Density | 0.97 g/cm³. |
ThermalConductivity | 0.26 W/mK. |
ThermalExpansionCoefficient | 1.30E-4 1/K. |
SpecificHeatCapacity | 1.5 J/g K. |
Light transmission | 88% |
Colour | Clear. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | Czechia |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | 2.77 kg CO₂ eq/m² Self declared |
Recyclability | 100% Recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 20 % |
