ShieldFLEX P Mastic Asphalt Paving System
Verified by manufacturer over a year ago
BBA Agrément Certificate
Certificate type
ISO 14001 Environmental Management Systems
Certificate type
ISO 9001 Quality Management
Certificate type
Mastic asphalt paving; waterproofing, leveling and protection system.
Application
Can be used on horizontal, sloped and vertical surfaces. It is a proven way of topping car parks, lorry decks, bridges, walkways and platforms.
Description
A polymer modified paving grade of mastic asphalt, specifically designed for elevated decks, car parks, lorry decks, bridges, podiums and more. It has been designed, tested and certified as being durable enough for commercial traffic. The polymer modification allows the product to retain its integrity at lower temperatures, and on areas with more movement than that which conventional grades of mastic asphalt could withstand.
Technical characteristics:
- Specific gravity: 2.0-2.4.
- Water vapour permeability: 0.067% (g/day).
- Compressive strength (to BS EN 13892-2): 20 N/mm² (after five days).
- Flash point: <300°C.
Features and benefits:
- BBA Certified.
- Proven track record.
- Unapparelled durability for the application.
- Polymer modified to increase durability and extend life expectancy.
- Expected life in excess of 20 years when maintained correctly.
- ≥15 mm laying thickness (in 5 mm increments).
General information
Color | Black |
Finish | Sanded Guidance for specification option: generally crimped for added slip resistance |
Material | Asphalt |
Warranty description | 25 year Guidance for specification option: Up to |
Uniclass | |
CAWS | Q22/170 Proprietary vehicular paving |
Specification data - Mastic asphalt (MA) surface courses
Standard | To BS EN 13892-2, BS 6925:1988, BS EN 1992-1-1:2004, BS 8218:1998, EN 13501-5:2005. |
Third party certification | BBA Certified - 17/5452. |
Constituents | |
Aggregate size (maximum) | 10 mm. |
Binder designation | Polymer modified bitumen (PMB). |
Colour | Black. |
Recycled content (maximum) | 10%. |
Density | 2100–2150 kg/m³. |
Curing time | Light foot traffic: 30–50 minutes; full traffic: 24 hours. |
Sustainability data
Country of product manufacture | United Kingdom |
Recyclability | 100% recyclable |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 10 % Guidance for specification option: Up to |
Third party certifications
Third party certifications
BBA Agrément Certificate
17/5452 ShieldFLEX P Paving Deck System
ISO 14001 Environmental Management Systems
ISO 14001 Environmental Management System
ISO 9001 Quality Management
ISO 9001 Quality Management System
Literature
ShieldFLEX Mastic Asphalt Waterproofing System
