Sky Garden Sedum Modular Tray System - Green Roof Modular Tray System
Verified by manufacturer 13 days ago
Lightweight modular trays with pre-cultivated sedum plants for extensive green roof applications, easy to install and maintain.
Application
Suitable for extensive green roof applications on flat or gently sloping roofs where lightweight, modular, and easy-to-install vegetation systems are required.
Description
Sky Garden’s Modular System offers an alternative to conventional loose-laid Green Roof systems. Lightweight and fast to install, the system also offers the advantage of being easy to lift for roof inspection and to lift modules at any time if required.
Features and benefits:
- Instant vegetative cover for Extensive Sedum Blanket System.
- Trays can be lifted and reconfigured easily.
- Low maintenance.
- Trays slot next to each other for easy installation.
General information
Color | Green Other |
Finish | Natural |
Material | Vegetation Soil Polypropylene |
Shape | Rectangle |
Length | Bespoke 600 mm |
Width | Bespoke 400 mm |
Height | Bespoke 80 mm |
Warranty description | Lifetime |
Uniclass | |
CAWS | Q37/130 Extensive green roofs and biodiverse roofs |
SKU Code | SGMOD01 |
Specification data - Extensive green roof systems
Classification data | |
Protection | |
Protection layer | 3.5 mm Sky Garden Protection Fleece (PF01). |
Planting systems | |
Planting medium | Sky Garden Sedum Modular Tray (SGMOD01). Guidance for specification option: For Warm or Cold Roofs. Sky Garden Protection Fleece (PF01) should be laid on top of the waterproofing. Then the Sky Garden Sedum Modular Tray (SGMOD01) is installed. |
Planting requirements | Pre-cultivated sedum species. Guidance for specification option: 13 species. |
Fire breaks | 20–40 mm Sky Garden Riverstone (RS01). Guidance for specification option:
|
Components | Perforated polypropylene tray, growing medium and vegetation. Guidance for specification option: Modular 600 x 400 x 80 mm tray. |
Weight | 82 kg/m². Guidance for specification option: Saturated. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Manufacturing plant location | |
Material | Vegetation Soil Polypropylene |
Recyclability | 100 |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 100 % |
Expected Life | Lifetime |
