Square Lever Handle (HUKP-0501-02) - Door handle
Verified by manufacturer 5 months ago
Stainless steel lever handle sprung on square rose.
Application
Suitable for 38-50 mm door thickness.
Description
Stainless steel lever handle, modern design and sprung on square rose.
Features and benefits:
- Modern design lever handle pivot fitted into a square rose.
- Designer: Maurizio Giordano.
- Sprung, for use with standard duty followers.
- 50 mm square and 10 mm thick rose, tested to over 200 000 cycles.
General information
Color | Black Silver Gold Grey |
Finish | Matt Guidance for specification option: Black. Polished Guidance for specification option: Chrome. Satin Guidance for specification option: Chrome, nickel and brass. |
Material | Stainless steel Steel |
Shape | Square |
Length | 130 mm |
Width | 66 mm |
Height | 50 mm Manufacturer guidanceSquare rose thickness 10 mm. |
Warranty description | Seven year |
Uniclass | |
CAWS | P21/610 Lever handles P21/38 Lever handles |
Product range |
Specification data - Door lever handle sets
Standard | To BS EN 1906: 2012. |
Classification grades (minimum) | |
Category of use | 3. |
Durability | 7. |
Fire resistance | 0. |
Safety | 0. |
Corrosion resistance | 5. |
Security | 0 |
Type of operation | B. |
Style | Flat pattern. |
Size | 130 x 66 x 50 mm.Manufacturer guidanceSquare rose thickness 10 mm. |
Material and finish | Stainless steel, grade 1.4301 (304). |
Colour | Matt black.Satin brass.Polished chrome.Satin nickel.Satin chrome.Anthracite. |
Mounting | Sprung rose with bolt through fixing.Manufacturer guidanceRoses pierced at 38mm centres for M4 bolt through fixing. |
Literature
3. Project - Architectural Lever Handles
