Stratophone - Laminated safety glass
Verified by manufacturer 6 months ago
Sound attenuation: 36 dB
Sound attenuation: 36 dB
Laminated safety glass solutions providing delivering high-level acoustic insulation.
Application
Suitable for locations where safety and acoustic insulation are required, including:
- Doors and partitions;
- Facades and curtain walls;
- Shopfronts;
- Windows.
Description
Laminated safety glass solutions providing delivering high-level acoustic insulation that absorbs sound and blocks out noise.
Features and benefits:
- Includes an acoustic PVB interlayer.
- Provides the same safety protection as Stratobel.
- Certified tests (available on request) validate the performance of each product composition in terms of ageing (EN 12543) or resistance to soft impact (EN 12600).
- By incorporating special PVB interlayers, special tinted float glass and/ or coatings, additional functionality can be added to the existing safety functionality.
- Multifunctional: Ability to combine aesthetics, safety and other functions, such as solar control and thermal insulation in a single product.
- Sustainable: Cradle to Cradle Certified™ Silver.
- Noise reduction certificates available on request.
- Ten-year warranty.
General information
Color | Clear |
Material | Glass |
Shape | Rectangle |
Warranty description | Ten year |
Uniclass | |
CAWS | L10/400 Composite windows H10/10 Patent glazing L40/430 Single glazing into grooves – non-setting compound L40/260 Bead-fixed single glazing – extruded gasket L40/450 Single glazing into grooves – sealant capping L40/410 Single glazing into grooves – extruded rubber/ PVC sections H10/115 Patent glazing L40/310 Bead-fixed single glazing – tape, sealant and trim L10/33 Proprietary windows L10/31 PVC-U windows L10/30 PVC-U windows L10/25 Aluminium windows L10/20 Steel windows L10/10 Wood windows L40/350 Bead-fixed single glazing – curing compound and trim L40/230 Bead-fixed single glazing – non-setting compound L40/490 Single-sided gasket glazing L10/390 Proprietary windows L10/350 PVC-U windows L10/330 Aluminium windows L10/310 Steel windows L10/210 Wood windows L40/250 Bead-fixed single glazing – tape and sealant L40/330 Bead-fixed single glazing – capping H13/115 Structural glass assembly H11/110 Curtain walling L40/50 Bead-fixed single glazing |
Specification data - Laminated glass sheets
General requirements | Glass generally. |
Third party accreditation | Cradle to Cradle Certified™ Silver. |
Laminate glass type | Acoustic control; Safety. |
Thickness | 7 mm (33.2).Guidance for specification option: Two 3 mm-thick panes with two interlayers. Weight: 16 kg/m². |
Inner leaf | As Outer leaf. |
Interlayer to glass leaves | Minimum two PVB interlayers including one acoustic interlayer. |
Body colour | Clear neutral.Guidance for specification option: Default for Clearlite, Clearsight, Clearvision, Planibel Low-E, Sunergy and Matelux. Coloured.Guidance for specification option: Insert requirements. Not available for Clearlite, Clearsight, Clearvision, Planibel Low-E, Sunergy or Matelux. |
Performance requirements | |
Light | Manufacturer's standard.Guidance for specification option: Varies depending on outer leaf option specified; consult manufacturer for details. |
Solar control | Manufacturer's standard.Guidance for specification option: Varies depending on outer leaf option specified; consult manufacturer for details. |
Total shading coefficient | Manufacturer's standard.Guidance for specification option: Varies depending on outer leaf option specified; consult manufacturer for details. |
Fire performance | |
Integrity | Manufacturer's standard. |
Insulation | Manufacturer's standard. |
Radiation | Manufacturer's standard. |
Sound attenuation | Acoustic index (Rw C; Ctr): 36 (0;-3) dB. |
Impact resistance | Manufacturer's standard. |
Security | Manufacturer's standard. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Europe |
Country of product manufacture | Europe |
Literature
Acoustic Glass Performance Values by AGC
