StressPly® SA Flex Bitumen Flat Roof
Verified by manufacturer 5 months ago
BBA Agrément Certificate
Certificate type
Superior self adhesive modified bitumen membrane.
Application
Suitable for warm and cold roof systems.
Description
Combining the use of self-adhesive membranes, hot air welding and solvent-free adhesives, Stress Ply Flex SA System is a flame-free modified bitumen system.
The system features the same durability and robust waterproofing benefits as multi-ply torch-on bitumen membranes, without the need for naked flame.
The membrane laps feature a self-adhesive compound technology, allowing laps to be partially sealed without the need for flame and does not risk burning heat-sensitive insulation board or combustible deck materials during the hot-air welding process.
Features and benefits:
- 20 year single-point guarantee.
- European fire safety standard using CEN/TS 1187 Test 4.
- NFRC Safe2Torch compliant.
- Classified to EN 13501-5 with a result of Broof(t4).
- Compliant with Building Regulation and Approved Document B.
System includes:
- StressPly SA Flex (cap sheet)
- SA Base
- SA Flex VCL
- SA Contact Primer
- Insul Bond
- Insul Loc
- Insul Pro
- Xtratherm-FRBGM
- Tapered-roof-TR-MG
General information
Finish | Textured Guidance for specification option: Slate granules. |
Material | Bitumen |
Length | 10000 mm |
Width | 1000 mm |
Warranty description | 25 year |
Uniclass | |
CAWS | J41/110 Built-up reinforced bitumen membrane warm deck roof covering J41/400 Built-up reinforced bitumen waterproof covering J41/10 Reinforced bitumen membrane warm deck roof covering |
Specification data - Reinforced bitumen membrane warm roof covering systems
Preparation | |
Horizontal work | SA Contact Primer. |
Skirtings and vertical work | SA Contact Primer. |
Air and vapour control layer | |
Type | SA Flex VCL 3 mm x 10 x 1 m.Guidance for specification option:
|
Attachment | Silicone release film with self-adhesive elastomeric compound.Guidance for specification option: SA Flex Vapour Barrier |
Insulation | |
Type | Xtratherm TR/MG Tapered Roof Board A60, 1200 x 1200 mm.Guidance for specification option: 30-50 mm. Xtratherm TR/MG Tapered Roof Board B60, 1200 x 1200 mm..Guidance for specification option: 50-70 mm. Xtratherm TR/MG Tapered Roof Board C60, 1200 x 1200 mm.Guidance for specification option: 70-90 mm. Xtratherm TR/MG Tapered Roof Board D60, 1200 x 1200 mm.Guidance for specification option: 90-110 mm. Flat RoofBoard FR/BGM, 1200 x 600 mm.Guidance for specification option: Available in the following thicknesses: 25, 50, 60, 70, 80, 90, 100, 110, 120, 130, 140 mm. Insert requirements. |
Fixing | The specification for fixing Xtratherm roof boards will vary with the location, roof height/width and topographical data. |
Waterproof covering | |
First layer | |
Type | SA Flex Base Sheet 3 mm x 10 x 1 m.Guidance for specification option:
|
Attachment | Silicone release film with self-adhesive elastomeric compound. |
Top layer | |
Type | StressPly Flex SA, 4.2 mm x 10 x 1 m.Guidance for specification option:
|
Attachment | Silicone release film with self-adhesive elastomeric compound. |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Third party certifications
BBA Agrément Certificate
StressPly Flex SA BBA Certificate: 22/6553
Literature
Garland - High Performance Waterproofing Solutions for Modified Bitumen, Cold Applied Liquid Coatings, Maintenance Products and Metal Cladding & Standing Seam
Garland UK - Green Shield Extensive Green Roofing Systems
Garland UK - Solarise Photovoltaic PV solar energy systems
