Taralay Impression HOP Acoustic – Loose Lay Sheet - Heterogeneous flooring

Verified by manufacturer 8 months ago

0543 - CEMENTO BRESCIA

Gerflor Flooring UK Limited Variant:

Multi-layered, loose lay vinyl floorcovering, integrating 2 fibre layers with a compact interlayer, a very high density foam backing and a printed design.

Jump to:
BOS
01625 428 922 Website

Application

Taralay Impression HOP Acoustic is a loose lay commercial floorcovering suitable for high traffic healthcare, education, commercial and public areas.

Description

Taralay Impression HOP Loose Lay Acoustic is a multi-layered construction, acoustic vinyl sheet floor covering with a 0.7 mm wear-layer and patented Protecsol® 2 surface treatment. It requires no wax for life, delivering ease of maintenance and energy savings. With its 2 fibre layers, a veil and a grid with a compact interlayer, the floorcovering achieves a high level of stability, even under temperature variations and heavy rolling loads. Its construction, including a very high density foam backing, delivers 19dB of impact sound redution. It can be laid down onto various existing supports, including asbestos. It is suitable for renovation or new buildings construction. Without any glue, its end life removal is fast and easy. Available in 30 design references.


Features and benefits:

  • Protecsol® 2 surface treatment which eliminates the need for waxing.
  • Easy and cost-effective maintenance, with less water and detergent use.
  • Loose lay installation.
  • Durable construction – suitable for high traffic applications.
  • 19dB impact sound insulation.
  • R10 slip resistance rating.
  • Highly flexible, easy to install and weld.
  • Compatible with the Gerflor Clean Corner system.
  • End life removal is fast and easy.
  • 100% recyclable and contains 15% recycled content.
  • Also available as Taralay Impression HOP Compact (loose lay), Taralay Impression Compact and Taralay Impression Acoustic - all specified separately.
  • The Taralay Impression range can be customised using digital print technology. Contact manufacturer for details.


Installation and maintenance:

Should be installed in accordance with the BS 8203: 2017 Code of practice for installation of resilient floor coverings. Installation and maintenance instructions are available. Can be installed with the patented Clean Corner System for ensured hygiene.

General information

Color

Brown

Clear

Beige

Grey

Other

Finish

Matt

Material

Vinyl

Length

20000 mm

Width

2000 mm

Height

4.35 mm

Warranty description

12 year

Uniclass

Pr_35_57_71_32 Foam-backed polyvinyl chloride (PVC) sheetsPrimary

CAWS

M50/20 Sheeting

M50/150 Sheeting

Product range

Sheeting / Heterogeneous Comfort Flooring

Specification data - Foam-backed polyvinyl chloride (PVC) sheets

Standard

EN ISO 11638

Use class

To BS EN ISO 10874, class 34–42.

Guidance for specification option:

Commercial, very heavy – Light industrial, heavy.

Recycled content

15 %.

Width

2000 mm.

Thickness

4.35 mm.

Colour and pattern

0543 Cemento Brescia.

Wear layer

0.70 mm.

Weight

3670 g/m².

Static electricity

<2 kV.

Guidance for specification option:

BS EN 1815 static electricity electrical propensity.

Fire classification (EN 13501-1)

Bfl-s1.

ThermalConductivity

0.25 W/m·K.

Guidance for specification option:

To EN ISO 10456.

Surface treatment

Protecsol® 2.

Wear group

T.

Impact sound reduction (to EN-ISO 717-2)

19 dB.

VOC emissions

<10 µg/m³.

Guidance for specification option:

TVOC after 28 days (to ISO 16000-6).

Residual indentation (to EN-ISO 24343-1)

≈ 0.08 mm.

Guidance for specification option:

Average measured value ≈ 0.08 mm. Requirement ≤ 0.20 mm.

Dimensional stability

≤ 0.40%.

Guidance for specification option:

To EN ISO 23999.

Colour fastness

≥ 6.

Guidance for specification option:

To EN 20 105 - B02.

Light reflectance value (LRV)/ Colour

32.5.

Slip Resistance

R10.

Guidance for specification option:

Slip resistance wet : ramp test with oil - to EN 16165 app B.

Length

20 m.

Sustainability data

Contains Red List materials

No

Country of product manufacture

France

Recyclability

100 %

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

15 %

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

Chemical Resistance Results

Chemical Resistance Results

Taralay Impression Binder

Taralay Impression Binder
