Technics 5 - Underlay

Name: Technics 5 - Underlay
Brand: Interfloor Ltd
SKU: kfW6WRvZtUoQTWEWyAk2hg

Verified by manufacturer 4 months ago

Interfloor Ltd

Third party certifications:

EPD
Certificate type

Underlay suitable for the double-stick and stretch-fit installation of carpets, and floating wood and laminate installations.

Jump to:

+44 (0)1706 238820 Website

Application

Suitable for the double-stick and stretch-fit installation of carpets, and floating wood and laminate installations.

Description

Underlay suitable for the double-stick and stretch-fit installation of carpets, and floating wood and laminate installations.

Features and benefits:

Sponge rubber (flat).
Green Label Plus certified.
Suitable for underfloor heating and flame retardant applications.
End use classification (to BS 5808): HC/U, heavy contract use.
Contains not less than 3% post-consumer recycled material. MR 4.0 points available.
At the end of the underlay's useful life it can be 100% recycled. MR 2.0 points available.
Regional materials: Where used within 500 miles of production facility, MR 5.0 points available.
Meets or exceeds the industry standard for indoor air quality as established by the CRI Green Label Programme. IEQ 4.3 points available.
Antimicrobial and mildew resistance: Pass.
Russian GOST FR Test Classification: KM3.
US Critical radiant flux: NFPA class I.
US Methenamine Pill Test: Pass.
US Smoke Chamber Test: Pass.

General information

Color	Black
Finish	Other
Material	Rubber
Shape	Other
Length	1.37 mm
Width	0.27 mm
Height	0.27 mm
Warranty description	Lifetime

Uniclass	Pr_35_57_11_13 Cellular rubber underlaysPrimary
CAWS	M50/170 Carpeting M50/25 Carpeting

Product range	Carpet Underlays

Specification data - Cellular rubber underlays

Use class	HC/U.
Thickness (minimum)	5 mm. Manufacturer guidance Nominal.
Recycled content	0% post-consumer. 3% pre-consumer. 97% virgin.

Area	15.07 m². Manufacturer guidance Roll area.
Roll size	1.37 x 11 m.
Roll weight	40.9 kg. Manufacturer guidance Nominal.
Odour	No objectionable odour.
Colour	Black.
Backing	Printed Textron backing.
Impact sound reduction	28 dB. Manufacturer guidance Delta Lw.
VOC emissions	Complies A+. Guidance for specification option: Accreditation 0754 to US CRI Green Label Plus programme. Manufacturer guidance French VOC emission regulations.
Thermal resistance	0.56 togs.
Thermal resistance (R-value)	0.0056 m²K/W.
Compression	96 J/m² work of compression (minimum 50 J/m²). 89% retention of work of compression (minimum 40%). 2.2 mm compression after dynamic loading. Manufacturer guidance Technical characteristics.
Breaking strength:	282/ 162 N. Manufacturer guidance Breaking strength, minimum 40 N (length/ width).
Extension	0.8/ 0.5%. Manufacturer guidance Extension under force, maximum 10% at 40 N (length/ width).
Resistance	Pass. Manufacturer guidance Resistance to cracking (not greater than 50 mm).
Performance	5.6 PSI. Guidance for specification option: 25% deflection. 20.9 PSI. Guidance for specification option: 50% deflection. 81.6 PSI. Guidance for specification option: 65% deflection. Manufacturer guidance Test performance to US standards. CFD (Compression Force Deflection).
Performance class	Extra heavy commercial class III. Manufacturer guidance Recommended use.
Flammability	Low radius of ignition. Manufacturer guidance Hot metal nut test.
Reaction to fire classification	Bfl-s1. Manufacturer guidance Tested in conjunction with Axminster 80:20 carpet.
Nominal weight	2712 g/m². Manufacturer guidance Nominal square weight.
Nominal density	542.4 kg/m³.
Technical characteristics, other	3.5 % after dynamic loading. 4% after static loading. Manufacturer guidance Loss in thickness (maximum 15%).

Sustainability data

Contains Red List materials	No
Country of product manufacture	United Kingdom Guidance for specification option: Haslingden, BB4 4LS, UK.
Material	Rubber
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	48.67 kg CO₂ eq/unit
Recyclability	100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	3 % Manufacturer guidance 0% Post-consumer. 3% Pre-consumer. 97% Virgin.

Third party certifications

Double Stick Flat Sponge Underlay

Third party certifications

EPD

Double Stick Flat Sponge Underlay
