Name: Terrazzo - Raised Access Floor System
Brand: Parkside Architectural Tiles
SKU: gkP4deDzjHbV7k5NBG8JQF

Color

Beige

Brown

Green

White

Cream

Finish

Polished

Brushed

Honed

Unfinished

Material

Marble

Resin

Calcium sulphate

Steel

Glass

Shape

Square

Length

600 mm

Width

600 mm

Height

12 mm

Manufacturer guidance

Terrazzo thickness.

Uniclass

Ss_30_20_70_70 Raised access floor systemsPrimary

CAWS

K41/130 Raised access floor

K41/130 Proprietary raised access floor

Classification data

Subfloor preparation

Manufacturer guidance

Insert requirements or omit.

Support structure type

Access floor pedestals - MPS.

Guidance for specification option:

A solution for locals where floor height is reduced and/ or load requirements are light/ medium. Available heights from 35 mm to 600 mm.

Access floor pedestals and stringers - MPL.

Guidance for specification option:

The structure with open cross-sectional stringers allows maximum stability of the floor even without gluing the columns to the supporting slab support.

Access floor pedestals and stringers - MPM.

Guidance for specification option:

The substructure with medium resistance and open section stringers is suitabel for rooms with medium/ high load requirements and traffic. Heights from 35 to 1000 mm.

Access floor pedestals and stringers - MPH.

Guidance for specification option:

The substructure with closed rectangular stringers allows to reach high loads. Suitable for technical rooms and high traffic areas.

Access floor pedestals and stringers - BPC.

Guidance for specification option:

A solution for maximum performance, which ensures rigidity and electrical continuity due to the rectangular section closed stringers 50 x 25 mm.

Access floor pedestals and stringers - TR.

Guidance for specification option:

Specifically designed for technical areas such as data centres and is characterized by the pedestals' high load performance and positioning flexibility.

Pedestal fixings

Not required.

Epoxy resin-based adhesives.

Polyurethane (PUR) adhesives.

Raised access floor surface

Raised access floor panels, chipboard core, with terrazzo finish.

Guidance for specification option:

Core produced with FSC® chipboard in class E1, with very low formaldehyde emissions and high density 730 kg/m³. It represents a solution with good performance, suitable for projects that do not require high loads or have limited budgets.

Raised access floor panels, calcium sulphate core, with terrazzo finish.

Guidance for specification option:

Core composed of a monolithic layer of calcium sulphate, anhydrite-reinforced with recycled cellulose fibers, reaction to fire in class A1. Calcium sulfate panels offer high-performance characteristics and are EPD certified making them also suitable for projects with high sustainability standards.

Raised access floor panels, sintered material core, with terrazzo finish.

Guidance for specification option:

Core made of inert and inorganic material, with very high density (2200 kg/m³). Resistant to temperature changes, non-absorbent and frost-resistant. Suitable for high humidity environments or outdoor spaces, in the version without edge trim.

Manufacturer guidance

The bottom covering of the raised floor panels can be of various types:

Anti-dust primer, only for calcium sulphate panels.
Aluminum foil, 0.05 mm thick, contributing good protection against the possible humidity under the floor.
Galvanized steel sheet, 0.4 mm thick, ensuring protection against humidity and improving the panel’s mechanical resistance.

Insert requirements.

Samples required

Manufacturer guidance

Insert requirements or omit.

System accessories

Manufacturer guidance

Consult manufacturer and insert requirements or omit.

Colour/ Finish

900.

Brecciati.

Venati.

Marghestone.

Palladio.

Palazzo.

Manufacturer guidance

Each terrazzo collection is available in a range of colours. Finishes options include polished, honed, brushed or unpolished. Consult manufacturer’s literature and insert requirements.
