Timber Staffline Doors

Verified by manufacturer 10 days ago

Safetell Ltd

Internal timber security doors that provide bullet and manual attack resistance.

Jump to:
+44 (0)1322 223233 Website

Application

Internal timber security doors that provide bullet and manual attack resistance. Typical applications include cash offices, banks, retail, rail, airports, corporate buildings, government offices and internal secure areas.

Description

Safetell’s internal timber security doors provide bullet and manual attack resistance. Safetell Ltd can provide standard or bespoke solutions to match project requirement.

Features and benefits:

  • Manual attack and/or bullet resistant.
  • Standard certified doors have a single leaf and frame.
  • Secured by a Chubb 3R35 keylock.
  • Standard opening is outwards towards the attack side.
  • Timber standard finish in American White Oak.
  • Other optional finishes are available on request.
  • Standard heavy duty door closer for commercial use.
  • Uncertified inward opening doors are available but not recommended.
  • Kick plates, push plates and D handles are available.
  • Eye viewer, single or multiple vision panels with or without vertical venetian reflector strips to obscure public view.
  • Bespoke door finishes are available on request.
  • Bespoke automated door opening, access control and remote locking integration solutions are available to suit project requirements.
  • Uncertified double leaf Staffline doors and frame are available subject to limitations in attack resistance.
  • CEIA metal detector.

General information

Color

Brown

Finish

Woodgrain

Material

Timber

Shape

Rectangle

Length

115 mm

Manufacturer guidance

Depth.

Width

700 mm

Guidance for specification option:

Minimum.

1200 mm

Guidance for specification option:

Maximum.

Height

1800 mm

Guidance for specification option:

Minimum.

2400 mm

Guidance for specification option:

Maximum.

Uniclass

Pr_30_59_24_97 Wood doorsetsPrimary

CAWS

L20/55 Doorsets

L20/480 Doorsets

L20/430 Wood doorsets

L20/420 Wood doorsets

Specification data - Wood doorsets

Classification data

Configuration

Single-leaf, single-action.

Guidance for specification option:

Standard opening is outwards towards the attack side.

Doorset size

-

Manufacturer guidance

Consult manufacturer and insert requirements.

  • Height: 1800–2400 mm.
  • Width: 700–1200 mm.

Performance

-

Bullet resistance

Not required.
To BS 5051, G2 and S86.

Manufacturer guidance

Optional bullet resistance to client specification, consult manufacturer and insert requirements.

Frame

-

Material

Hardwood.

Species

American white oak.

Finish

American white oak.
Bespoke.

Guidance for specification option:

Bespoke door finishes are available on request. Consult manufacturer and insert requirements.

Colour

-

Manufacturer guidance

Insert colour requirements.

External

-

Manufacturer guidance

Insert colour requirements.

Internal

-

Manufacturer guidance

Insert colour requirements.

Installation fasteners

Manufacturer's standard.

Frame accessories

Heavy duty hinges.

Guidance for specification option:

Includes dog bolts and fitted with a T section to protect the leading edge of the door.

Door leaf

-

Thickness

115 mm.

Core

Solid core.

Facings

Wood veneer.

Species

American white oak.

Finish

American white oak.
Bespoke.

Guidance for specification option:

Bespoke door finishes are available on request. Consult manufacturer and insert requirements.

Colour

-

External

-

Manufacturer guidance

Insert colour requirements.

Internal

-

Manufacturer guidance

Insert colour requirements.

Glazing

-

Type

Not required.
Single vision panel.
Multiple vision panels.

Glazing accessories

Not required.
Vertical venetian reflector strips.

Door accessories

Not required.
Eye viewer.

Accessories

Not required.
Kick plates
Push plates.
D-handles.
CEIA metal detector.
Automated door opening.
Access control.
Remote locking.

Sustainability data

Material

Timber
