Vario Unlimited Rooflight

Name: Vario Unlimited Rooflight
Brand: VELUX Company Ltd
SKU: gbNpQP6DQ7s1kL9xbqiRkk

Verified by manufacturer 15 days ago

Unlimited rooflight.

Jump to:

BOS

Application

For roof pitches of between 5–15°.

Unlimited rooflight.

Features and benefits:

Each module available in fully bespoke sizes from 250–3000 mm with an impressive maximum of 4 m² edge-to-edge view of the skies above.
Vario's cleverly engineered gutter and beam connector system allows the combination of an endless amount of modules.
Freedom to combine fixed and vented modules.
Superior energy efficiency, achieving an astonishingly low thermal transmittance of Uw 1.1 W/m²K according to EN 14351-1 and with a 0.5 Ug value.
Opening rooflights are operated wirelessly and include a rain sensor as default.
Supplied with a laminated inner glazing as standard for superior safety in the unlikely case of breakage.
Includes a 150 mm insulated wooden upstand as standard (customisable between 150–600 mm).

Color	Black Grey Manufacturer guidance Available in RAL 7043 gloss 30 (Traffic grey) or RAL 9005 gloss 30 (Jet black) as standard.
Finish	Powder-coated Manufacturer guidance Powder coated
Material	Glass Aluminium Plywood Manufacturer guidance Aluminium and plywood.
Shape	Rectangle Square Manufacturer guidance Square/ rectangular.
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Ten year Guidance for specification option: Guarantee for the windows and panes. Three year Guidance for specification option: Guarantee for electrical items and blinds.

Uniclass	Pr_30_59_72_31 Framed rooflightsPrimary
CAWS	L10/460 Rooflights L10/45 Rooflights

Product range	Vario by VELUX Bespoke Flat Rooflights

Form	Unlimited rooflight for flat roof.
Size	As drawing. Guidance for specification option: Insert reference, each module available 250–3000 x 250–3000 mm, 3 m²/ 4 m² maximum area (triple glazed/ double glazed), structural opening is +30 mm. As schedule. Guidance for specification option: Insert reference, each module available 250–3000 x 250–3000 mm, 3 m²/ 4 m² maximum area (triple glazed/ double glazed), structural opening is +30 mm.
Product performance	-
Fire performance	-
Fire resistance	External fire classification of BROOF(t4) according to EN 13501-5:2016.
Reaction to fire	Class B-s1, d0.
Whole window U-value	1.1 W/m²K.
Frame	-
Material	5 mm thick aluminium.
Finish	-
Coating	Powder coated.
Colour	RAL 7043 gloss 30 (Traffic grey). RAL 9005 gloss 30 (Jet black). Special order. Guidance for specification option: Insert requirement.
Glazing or infill	-
Type	Double glazed. Triple glazed.
Construction	Laminated inner pane, UV protecting.
Coating	LowE as standard.
Integral kerb	Plywood, water based white coating, RAL 9010 gloss 30.
Operation	-
Type	Automatic, motorized. Fixed.
Control	Not applicable. Guidance for specification option: For fixed. Wireless controls and rain sensor.
Accessories	None. Burglary resistance. Sun protection. VELUX ACTIVE smart home control.

Upstand height	150 mm. Guidance for specification option: Standard. Special order. Guidance for specification option: Insert requirement, available 150–600 mm.
