Venticello Vanity Washbasin 4104 8L XX
Verified by manufacturer 8 months ago
Venticello Vanity Washbasin 41048G
Venticello Vanity Washbasin 41048G
Vanity washbasin, rectangle.
Description
Rectangular vanity washbasin manufactured in accordance with EN 14688 and EN 31.
Features and benefits:
- Manufactured using sanitary ceramics.
- Wall fastening.
- Outlet valve with ceramic cover optionally available.
- Suitable for three-tap hole fittings, central tap hole punched out.
General information
Color | White |
Material | Ceramic |
Shape | Rectangle |
Width | 500 mm |
Uniclass | |
CAWS | N13/335 Washbasins |
Product range |
Specification data - Wall-hung washbasins
Standard | To BS EN 14688. |
Form | Wall hung wash basin. |
Materials | |
Body | Ceramic. |
Finish and colour | Stone White CeramicPlus.White Alpin.White Alpin CeramicPlus. |
Size | 800 x 500 mm. |
Water supply, overflow and waste holes | |
Water supply | Single tap hole, centred. |
Overflow | None.Guidance for specification option: A non-closable outlet valve required. |
Waste | Bottom waste outlet. No chainstay hole. |
Accessories | None. Cap (overflow cover) 790100. Guidance for specification option: Diameter: 41 mm. Closable valve 680600. Guidance for specification option: Manufactured to EN 247. Diameter: 32 mm. Ceramic valve cover. Easy access siphon 921988. Guidance for specification option: Manufactured to EN 247. Diameter: 32 mm. Push-to-open valve 8L0334. Guidance for specification option: Manufactured to EN 247. Diameter: 32 mm. |
Weight | 21.6 kg. |
Sustainability data
Material | Ceramic |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 2 |
 IFC | - | 1 |
 ARCHICAD | - | 1 |
 OBJ | - | 1 |
 SketchUp | - | 1 |
 3Ds Max | - | 1 |
