Summary
Enclosed shelters with optional front panels or shutters.
Enclosed shelters with optional front panels or shutters.
Application
Shelter providing protection from the elements for workers, visitors and equipment.
Shelter providing protection from the elements for workers, visitors and equipment.
Description
Enclosed shelters with optional front panels or shutters.
Features and benefits:
- Creates an enclosed area manufactured from steel and cladded with polycarbonate sides.
- Cost effective way of utilising space to increase productivity.
- Fully customizable to include doors, roller shutters, solar lighting, and more.
- Suitable for use outside a main or side entrance of a building to create an outside smoking or eating area.
- Steel construction is long lasting and hard wearing.
- Triplex anti-corrosion surface treatment guarantees the coloured shelter for 25 years.
- Alternative anti-corrosion surface treatment, hot-dip galvanizing and epoxy powder-coating, also available to respective ISO and BS EN standards.
Enclosed shelters with optional front panels or shutters.
Features and benefits:
- Creates an enclosed area manufactured from steel and cladded with polycarbonate sides.
- Cost effective way of utilising space to increase productivity.
- Fully customizable to include doors, roller shutters, solar lighting, and more.
- Suitable for use outside a main or side entrance of a building to create an outside smoking or eating area.
- Steel construction is long lasting and hard wearing.
- Triplex anti-corrosion surface treatment guarantees the coloured shelter for 25 years.
- Alternative anti-corrosion surface treatment, hot-dip galvanizing and epoxy powder-coating, also available to respective ISO and BS EN standards.
Color
Black, Blue, Green, Grey, Red, Silver, White, Yellow, Other
Black, Blue, Green, Grey, Red, Silver, White, Yellow, Other
Finish
Powder-coated, Galvanized
Powder-coated, Galvanized
Material
Steel, Polycarbonate
Steel, Polycarbonate
Shape
Rectangle, Square
Rectangle, Square
Length
3000 mm, 4000 mm, 5000 mm, Bespoke
3000 mm, 4000 mm, 5000 mm, Bespoke
Width
3000 mm, 4000 mm, Bespoke
3000 mm, 4000 mm, Bespoke
Height
2600 mm, Bespoke
2600 mm, Bespoke
Warranty description
25 year
25 year
SKU Code
CWSF033, CWSF034, CWSF035, CWSF043, CWSF044, CWSF045, HCWSF033, HCWSF034, HCWSF035, HCWSF043, HCWSF044, HCWSF045
CWSF033, CWSF034, CWSF035, CWSF043, CWSF044, CWSF045, HCWSF033, HCWSF034, HCWSF035, HCWSF043, HCWSF044, HCWSF045
Specification
Classification data
Shelter description
Enclosed shelter.
Shelter with shutters.
Dimensions
-
-
Plan size
3000 x 3000 mm., 3000 x 4000 mm., 4000 x 3000 mm., 4000 x 4000 mm., 5000 x 3000 mm., 5000 x 4000 mm.
3000 x 3000 mm., 3000 x 4000 mm., 4000 x 3000 mm., 4000 x 4000 mm., 5000 x 3000 mm., 5000 x 4000 mm.
Height
2600 mm.
2600 mm.
Frame
-
-
Material
Structural steel.
Structural steel.
Finish
Triplex multi-layer powder coating to ISO 12944., Other.
Triplex multi-layer powder coating to ISO 12944., Other.
Colour
Black RAL 9005., Blue RAL 5002., Green RAL 6026., Anthracite Grey RAL 7016., Umbra Grey RAL 7022., Red RAL 3020., Silver RAL 7035., White RAL 9003., Yellow RAL 1021., Other., Not applicable.
Black RAL 9005., Blue RAL 5002., Green RAL 6026., Umbra Grey RAL 7022., Red RAL 3020., Silver RAL 7035., White RAL 9003., Yellow RAL 1021., Other., Not applicable.
Panels
4 mm polycarbonate, back, left and right.
4 mm polycarbonate, left and right.
Roof covering
16 mm triple wall polycarbonate.
16 mm twin wall polycarbonate.
Doors
-
Shutters, solid., Shutters, perforated.
Rainwater drainage
Guttering and downpipes.
Guttering and downpipes.
Accessories
None., Front panels.
-
Additional properties
Fixing
Manufacturer's standard.
Manufacturer's standard.
Sustainability data
Country of product manufacture
United Kingdom
United Kingdom
Material
Steel, Polycarbonate
Steel, Polycarbonate
