The FA wanted only the best for its highest-profile ‘social pitch’ at St George’s Park, its new centre of excellence in Staffordshire, opened in October 2012 by the Duke and Duchess of Cambridge – FA President Prince William wife, Kate.The fence at Pitch No 2, the David Beckham Pitch, needed to take sponsorship and branding and keep rattle and noise to a minimum. The FA also wanted to fit in with the landscaping of the National Forest in which the centre sits.The SolutionThe system had to be in keeping with the environment – even down to surfacing the pitch surrounding the same golden colour as the car parks. In addition, it needed to limit noise impact on neighbours and cause minimal disruption to pitch use during installation as the fencing went in after the pitch.They chose a quality system that will last on this high-usage pitch at heights of 2m and 5m with EPDM inserts to insulate the fence panels from the posts to reduce noise during impacts to 72dB compared with the 93dB of wooden panels.Zaun designed its Super Rebound to take branding and sponsorship signs and fencing to remain robust even in brisk winds when the graphics can threaten to act as a ‘sail’.The installation, which is around a pitch that is primarily used by the public rather than for England training, carriesZaun’s industry-leading 12-year product guarantee.Zaun worked closely with East Staffs Borough Council on planning consent and with the St George’s Park groundsmen and facilities team to complete a tight programme of works on the £105m complex on budget and in time for the royal opening.

Kent County Council wanted one-off architectural fencing for its keynote public square, the focal point of a new £16.5m town centre, to celebrate famous Ashford-born mathematician John Wallis.The scheme next to Victoria Road School in Ashford was designed by an artist to commemorate the work of Wallis, a pioneer who developed various mathematical theories and introduced the symbol for infinity. Unfortunately, it required a natural edge to the square that reduced visibility through to the school beyond.The SolutionZaun drew on its specialist bespoke construction skills to produce a complex fencing solution with parallel perforated panels of different-sized holes, creating a zany fence line up to a height of 4m.Different materials and finishes have been used to create an art trail with etched text and symbols relating to his work.Zaun and the main contractor, Volker Fitzpatrick, accommodated several changes from the original designs to reduce overall scheme costs. A pavilion was replaced with an additional planting area, and the architectural fencing was adapted.The £16.5m project secured funding from the Departments for Communities and Local Government and Transport.Victoria Way is a new route to the south of the town centre to link the International Station at Beaver Road and the A28 Chart Road providing better access to the heart of the town.The new road opened in late 2011, providing an attractive, tree-lined avenue from Victoria Road through brownfield industrial land to join with the A28 near Matalan, and includes John Wallis Square, public art displays and new shops restaurants, cafes and homes.

One of the largest and busiest ports in Europe required a major upgrade to its perimeter security fencing. Due to an increase of migrants trying to cross the borders illegally, there was a need to improve the fencing around the port to ensure people who did not have the correct paperwork or permissions to travel across the border were kept safe and out of harm’s reach whether it’s those attempting illegal breaches into the port site or those responsible for preventing them from doing so.The fencing was designed to prevent migrants from trying to stow away on trucks; usually, this would happen as the truck slows or comes to a stop, and the migrants would run and get inside the trucks to hitch a ride across the border.A migrant camp nearby, which it is reported housed more than 10,000 people, ensured a constant threat of illegal migrants trying to cross the border. Many displaced migrants congregate here in an attempt to cross the borders by illegal and dangerous means. People smugglers were a constant problem, many promising migrants jobs and security once they had crossed the border.The SolutionZaun HiSec 358 Fencing was installed along both sides of the main road into the port, which aimed to prevent the migrants from getting onto the vehicles as they slowed or came to a halt. This anti-climb mesh fencing system features 12.7mm x 76.2mm tight mesh apertures, which prevents people from getting a foothold and scale the fencing to get over and prevents objects from being passed through the fabric. It also provides resistance to cutting by conventional hand tools and is employed extensively in higher security applications supported with detection and surveillance technologies.In addition to the anti-climb mesh, Zaun’s Flexible Security Topping (FST) was also installed to the top of the fencing to ensure that anyone who did somehow manage to scale the fencing could not get a grip over the top of the fencing. FST is designed in such as way what it moves as people try to climb it. Installed with concertina wire, this provides the port with a fence that works as a visual deterrent and a practical one.High-security temporary fencing and barrier systems, including SecureGuard, were also installed around the port, which provides high security, a movable border that can not only be easily converted into a PAS68 HVM perimeter but is also movable if the perimeter needs reducing or expanding for any reason. This movable barrier system also featuring FST and concertina wire as a topping for an additional deterrent.

The G8 Summit in Enniskillen of the world’s most powerful politicians involved 4,700 Police Service of Northern Ireland (PSNI) officers and 3,600 from other UK forces in a security operation that cost about £60m.The PSNI wanted the securest G8 ever at a time of ‘severe terrorist threat’ and hoped that its reputation for dealing with public disorder plus unprecedented physical, cyber, technical and logistical protection would keep many potential protesters away.The SolutionPSNI approached Zaun to design, manufacture, project manage and install an ‘impregnable cordon’ around the world leaders to guarantee their security throughout the summit at Lough Erne.The rectangular site was protected on its long northeastern boundary by the Lough Erne lake. After extensive testing, Zaun designed its single largest ever temporary installation using two of its premier high-security fencing systems for the other three sides.It installed its 3.6m high SecureGuard PAS68 temporary security fencing along the 5.7km road to the southwest of the site, which runs broadly parallel with the lough. In addition, Zaun integrated rising arm barriers and 10 PAS68 gates for secure access control along the fence line.It also put in 1.7km of its award-winning Rapid Deployable System (RDS) at each end, creating a secure perimeter from the road to the edge of and into the lake.RDSZaun had to make several adaptations to its multi-award-winning RDS that was first used for four political conferences on the mainland in 2012 and bought by The Home Office to add to the National Barrier Asset.In addition to the cable system on the front of the fence line gives the system it's PAS68 rating of 30mph (PAS 68:2010 V/7500(N2)/48/90:11.6/0.0), Zaun incorporated further enhancements to prevent mob attack on the run-up to the summit. Both RDS and SecureGuard were extensively tested by PSNI and the Home Office against mob attacks. These tests will now form the basis of a new standard adopted by the Home Office when testing systems.Zaun also created specially designed posts to carry additional one-tonne weights to prevent movement on the 30-metre section of RDS fencing that actually tracked into the lake itself to discourage protesters from breaching the perimeter via the water.RDS was used on remoter areas around the edge of forest land, dirt tracks and grassy knolls with undulating ground, and boggy land at the airport to provide Airforce One and other presidential jet landings.

The MultiFence PAS 68 can stop a 7.5-tonne truck at both 30mph and 40mph. It has been designed to mitigate the security risks at all sites of critical importance, using leading industry technologies to combat attacks by vehicles.It combines the attributes of our standard system with additional testing to ensure it meets the stringent quality standards relating to vehicle restraint systems of BS EN 1317 Part 2. It can be used on both soft and hard ground.Featuring TVCB blocks approved by the Highways Agency for use, it is ideal for security applications at major events, as below-ground foundations are not required.Our RDS PAS68 crash fence system consists of panels and posts installed and removed within minutes. The system uses an RDS block with the appropriate post arrangement. Our RDS PAS68 fence system has been crash-tested and rated to BSI PAS68:2010 standard. This means it can stop 2.5-tonne and 7.5-tonne vehicles.The system provides the product attributes normally only found in permanent installations. In addition, its simple deployment means the on-site disruption usually associated with installing and removing a fence line is kept to a minimum.Zaun also supplied our HiSec 358 anti-climb mesh fencing to combat the issue of intruders being able to scale the fence.InnovationCPNI and the Government were concerned about the threat of a ladder or other climbing aids used to lean against CCTV columns, making it easier to scale the fencing and gain entry into the secure area.Zaun’s solution was to create a number seven style CCTV column and base, which is completely self-supported and mobile and sits back from the fence line. Zaun’s design team created an innovative CCTV column featuring a unique number seven shape. This design meant the CCTV column would project over and outside the fence line, providing excellent visibility and obliterating the external climbing aid threat. The column was constructed from a custom-rolled, lightweight profile; it was also very easily installed on-site. The unique design also included a concrete base comprising a folded steel shell filled with concrete poured on-site. It incorporated forklift holes, ensuring the base is mobile and relocatable easily using a forklift or Moffatt on site.At the top of the base, a fixing system was designed, which allowed the columns to be attached and pivoted and then subsequently raised into the upright position with ease. This system allowed the CCTV installers to mount their cameras and other equipment to the top of the column at ground level before raising the column into place and negates the need for Mobile Elevating Work Platforms or MEWP’s.Zaun designed and manufactured more than 700 CCTV columns and bases to be used at the Commonwealth Games and are deployable for other events.

League regulations demand the installation of a rigid mesh fence with a spectator handrail around the perimeter of the pitch to a height of 1.1 metres. Zaun completed the complex supply and installation as changing ground levels required adaptation to ensure maintaining the 1.1m height around the whole pitch. Zaun contracts manager Steve Hancock visited the Haven Sportsfield Ground to take all of the site details for manufacture and supervised the installation, which was completed a week ahead of schedule.

For secure mental health units, the safeguarding of both their patients and the general public is paramount. Therefore, it is imperative that patients cannot leave the hospital grounds to ensure that they cannot threaten anyone or themselves. Therefore, secure, sturdy and reliable fencing is a necessity. However, to promote relaxation and recovery for anxious and agitated patients, it is necessary to maximise the capability of this fencing to ensure that it is restful rather than solely restrictive.So, how is it possible to ensure that high-security fencing can also be calming to patients?Secure Mental Health UnitsSecure mental health units in the UK require a high level of security because they often house people who have been previously incarcerated or those who have been admitted to the hospital after committing a crime. In addition, they deliver care to patients who may pose a risk to the general public and try to help their patients recover by offering accommodation, treatment and support.Patients in secure hospitals are not allowed to leave and cannot escape if they pose a danger to themselves or others. Therefore, the security is always extremely stringent inside and outside each unit.What are the Requirments of Secure Units?Security and safety of patients is a priority for NHS mental health units. A mental health unit is not a prison; it is a hospital where patients are cared for and nursed back to recovery with treatment and support. Patients mustn’t feel like they have been locked up, and the environment needs to be calming so that patients can enjoy the restful environment conducive to their recovery.However, it is also essential that patients not come and go because the unit delivers high-level security on a secure mental health unit. Therefore, any perimeter fencing must be extremely secure to keep the patients from leaving the hospital, and patients must also not be able to break down or scale the fencing.Therefore a duality must be created where a prison-like environment exists without the hospital being perceived as a prison by the patients on the unit.The SolutionZaun HiSec Prison fencing is used as a solution to all the requirements of secure mental health units. Every panel of the HiSec 358 close mesh fencing is specifically designed to ensure the safety and security of patients within the unit.In addition to the 358 mesh, the fencing features 1.5mm solid steel sheets, pre-galvanised, powder coated and printed with an image. This provides privacy to the patients inside while maintaining a high-security level. These sheets are then fixed to the fencing with a clamp bar on the post and clamped with an additional clamp bar mid bar to maximise their durability and sturdiness. To achieve tailored and bespoke results, sheets are pre-cut to size before arriving on-site, ready for installation.One of the most important facets of the fencing is the printed image on the front of the sheets. These images, often created by local artists, are created to calm the patients on the mental health unit, making them feel less anxious and improving their positivity. Therefore, they tend to depict calming imagery, such as lush flowers or relaxing scenery.This printed fencing has the dual outcome of keeping patients safe and secure inside the secure mental health unit and giving them restful images to views, such as vibrant yellow sunflowers and the glint of sunlight through woodland. In addition, viewing nature scenes has the benefit of positively improving mental health.

A former brownfield industrial site alongside the River Roding in Essex is converted into attractive mixed-use community housing. The Met Police custody and patrol base for the borough, industrial businesses, restaurants, river moorings and 1000 homes.The developer wanted to replace old and damaged wooden hoardings around a section of the Fresh Wharf Estate perimeter in Barking and prevent damage to a bus shelter from stone chips thrown up by passing vehicles on the adjacent A406.The SolutionFresh Water Developments approached Zaun to devise a bespoke solution for the site on the banks of the Roding, a Thames tributary. They wanted a sustainable perimeter, deflected flying stone chips, minimised noise and met their aesthetic, design and functional needs.Zaun has integrated a new highly resistant laminate made entirely from mixed waste plastics with its market-leading Duo fencing to produce a system that won’t rust or rot. In addition, it is low maintenance and reusable or recyclable if damaged.The innovative product design named DBS Security boasts great acoustic-loss properties, rated B3 and 36dB loss, and gives protection against damage from flying objects flicked up by passing vehicles.DBS Security protects a bus shelter close to the North Circular that constantly has to undergo repair. A large section of the perimeter to the industrial site and housing is fitted with Zaun’s twin-wire Duo fencing system. Two horizontal wires resist being welded on either side of the vertical wire.Zaun combined both standard and bespoke fencing to tailor the overall solution to the site’s specific requirements.

The city’s reputation assured under the spotlight of billions of viewersThe ChallengeCommonwealth Games hosts welcomed almost 5,000 athletes from 71 competing nations to the 20th Games at Glasgow 2014. They were the players on the stage across 18 sports, with the action broadcast to an estimated global audience of one and a half billion.For a fortnight of summer 2014, the eyes of the world were trained on Glasgow, so organisers had to deliver impeccable security to protect competitors, spectators, volunteers and dignitaries alike to preserve and enhance the city’s global image.The SolutionOrganisers awarded the prestigious contract as the Protective Perimeter Security provider to Selex ES, the Finmeccanica subsidiary, who turned to the largest supplier of perimeter fencing protection to the London 2012 Olympics.Selex ES handed almost £4 million of contracts to integrated high-security perimeter event overlay specialist Zaun to design, manufacture, install and decommission a broad vista of temporary high-security fencing systems across Glasgow 2014 sites.Together, they provided a wide range of physical security measures to secure over 20 Games venues at Glasgow 2014, including the Commonwealth Games Village for athletes and other Tier One venues such as the iconic Celtic Park, which was used for the opening ceremony, and Hampden Park, where the games officially closed.Zaun supplied several thousand metres of its MultiFence and award-winning RDS systems at heights of 3m and 2.4m, with sections fitted with Hostile Vehicle Mitigation (HVM) enhancements.Zaun also installed hundreds of vehicle and pedestrian gates and CCTV columns incorporated into the fencing.

London 2012 organisers wanted to protect temporary Games venues as securely as the main Stratford site. But they needed the perimeter protection to be removed as soon as the competition was over to minimise disruption to the local community.They also wanted to incorporate vehicle and pedestrian access along with CCTV and detection systems and tailor protection individually to each location and the security threat and attack potential identified by security advisers.The SolutionZaun offered a single Hostile Vehicle Mitigation (HVM) contract for almost 5km of fencing at all temporary venues, including Horse Guards Parade, Wembley Stadium, and Arena, Greenwich Park, the O2 Arena, the Royal Artillery Barracks, St James’s Park Newcastle and Weymouth sailing village. It developed a mobile high-security HVM fence especially for the Games, mounting its PAS 68 Multi-Fence® into concrete blocks to resist attack by 7.5-tonne vehicles driven straight at it at 40mph.MultiFence uses anti-climb mesh fencing and is available up to 5m high. One of the first temporary solutions to achieve PAS68: 2010 V7500(N2) 64/90: 5.0/0.0 is manufactured to BS EN 1317 Part 2 (vehicle restraint systems) and approved by the Highways Agency.The solution at each venue had to work with existing security and perimeters. Typically this entailed another ‘cordon of security around existing installations with access portals at strategic locations.Zaun secured the main TV and temporary CCTV control centres at Horse Guards and made Wembley safe – then dismantled the security cordon as soon as the last ball was kicked.

In preparation for the 2012 Olympics, where over 10,000 athletes from more than 200 countries competed in London, Zaun developed a walkway system that would enable technicians to work safely at height to install fencing as well as attach CCTV and security enhancements to the highest parts of the fencing.Project ChallengesThe project required a range of unique and innovative solutions because of the varied challenges that were in play. The system needed to adhere to strict health and safety regulations, especially as working at heights has many potential dangers, and worker safety is a huge priority. We needed to create a cost-effective solution that installers could use in various venues and areas.We also needed to ensure that this walkway system did not damage the 358 mesh. The walkway also needed to facilitate the repair and installation of Perimeter Intrusion Detection (PID) and pulse-monitored electric fencing systems and razor wire. As such, it was essential that installers could easily and safely access materials, equipment and tools.Biggest Sporting Event In The WorldAs the Olympics is one of the biggest events in the world, global attention was on London and the various venues needed to be as secure as possible. From camera operators and athletes to volunteers and security personnel, the huge number of people involved in the Olympics meant that the security team needed to be able to see as much as possible at all times. To do this, it was best to put the security monitoring equipment along the fence line to survey the whole area and reduce the requirement for additional civils for CCTV cameras. Security measures during big events like the Olympics need to be incredibly stringent. The installation of these surveillance and security measures is of utmost importance to the security of the entire event.Innovative Walkway SystemZaun designed and manufactured a unique walkway system that allowed installers to work at heights safely without damaging the mesh fencing. Our innovative system was designed specifically to support the installation and maintenance of 358 security mesh fencing, CCTV cameras and electric fencing at the top of the fence line. We created an innovative walkway solution that easily attached to 358 mesh so technicians could check and access the security measures whilst safely working at height.

When a significant UK security site needed a complete upgrade to its perimeter fencing, Zaun stepped in with a cost-effective and highly secure solution.The task aheadDue to the compassionate nature of the site, guarding against the physical threat and providing a visual screen was important. Therefore, the perimeter had to meet the high standards of the Centre for Protection of National Infrastructure [CPNI] and be capable of housing Perimeter Intrusion Detection Systems [PIDS] – a sensor mounted on the fence.As there was no current security fencing system that includes a visual block approved by CPNI, it was thought that two fences were required. One of these fences would provide high-security protection and the other a screen from prying eyes.Installing an additional conventional louvre screen would have been expensive and taken up too much room, so Zaun’s development team came up with a solution to address both of these issues.The Patent Pending system uses horizontal louvres that cleverly link into the mesh; this keeps cost and size down as the mesh itself becomes part of the louvre system. The furthermore, them grabs the wires as it is installed to ensure a tight fit, thus preventing rattles that might interfere with the acoustic PIDS system. This clever design saves costs and space. In addition, the product can be configured to provide varying degrees of screening.What Was SuppliedCPNI approved HiSec Super 6 high-security fencing system is designed for sensitive, high-profile sites. The vertical wires are 6mm in diameter with 76.2mm x 12.7mm spacings, enhancing a standard 358 system.Louvre privacy screens are easily attached to the robust fencing eliminating the need for two sets of fencing. Manufactured from 2mm thick steel sheets, which are folded to form the louvre. The galvanised sheets cleverly grab onto the mesh as they are installed, improving privacy and making the 358 mesh more rigid.This whole private and secure fencing system can also have PIDS easily attached. These mounted detection systems give early warning to any attempts of intrusion, whether penetration or climbing. It offers discreet monitoring and early warning and can be fitted on existing fencing units.

London 2012 organisers always planned, as part of their Olympic legacy, to transform the Athletes’ Village into a purpose-built education and leisure campus with a specialism in performing arts comprising a nursery, primary and secondary school, sixth form and adult learning.While the main base for organising and managing teams from the record 206 nations that took part would readily convert to their new educational purpose, they needed a fencing solution to reduce the impact of noise from the Tube line that runs alongside.The SolutionContractor Osborne, Academy architects Allford Hall Monaghan Morris, and Lend Lease Group, responsible for the design, development and construction of East Village, chose Zaun’s DBS acoustic fencing for the job.Zaun used mixed recycled waste plastics to develop the DBS panels that can deflect noise, soak up flying fragments, and be incorporated onto Zaun’s extensive range of fencing post and panel systems to tailor specifiers solutions to their precise needs.The panels are easy to erect and suffer shallow repair needs, significantly reducing the whole life cost of the fencing system. In addition, the panels’ impressive acoustic-loss properties have been rated B3 with a 36dB loss under BS EN 1793-2.The Chobham Academy, which incorporates the Beth Tweddle Academy for gymnasts, has been dubbed ‘the school with an Olympic playground’, with swimming lessons in the aquatics centre and sports days in the Olympic Stadium.It sits on the edge of the new East Village neighbourhood with 2,818 new homes, community health facilities and over 10 hectares of public leisure space.

Converting the former Olympic Stadium to the London Stadium when it became home to the West Ham football club was a significant civil engineering feat. The landmark structure on the capital’s skyline initially cost £486 million when built to house the 2012 London Olympics.A redevelopment between 2013 and 2016 to transform the Olympic monument into a football stadium for the Premier League club cost a further £323 million. The groundbreaking design included adding the most extensive cantilevered roof globally, powered by state-of-the-art technology typically used on North Sea oil rigs.Additionally, the group installed 21,000 new retractable seats to bring fans in the lower tiers closer to the action, while they also added new catering facilities, toilets and executive facilities. The former Olympic stadium was almost totally rebuilt to create a 54,000-seat dual-use arena that would still be suitable for athletics.Stadium fencing and gatesZaun was commissioned to supply security stadium fencing and gates for the London Stadium. This included our Duo8 SR1 fencing for the perimeter. This double wire welded mesh fencing system is suitable for applications that require Secured By Design accreditation. Tested and approved by BRE to LPS1175 SR1 (A1), this perimeter fencing system features the same benefits as our standard Duo8 perimeter fencing system but with additional security, such as tamper-resistant clamp bars and fixings. The Association of Chief Police Officers has approved it as meeting the Secured By Design accreditation.In addition, we also supplied our Super Rebound and Duo Sports Fencing for the sports pitch. It is a further development of the Duo Sports twin wire sport fencing solutions, designed for applications that have high usage for sports. It is ideal for use at sports pitches subject to high footballs, tennis balls, basketballs, hockey balls and more. It features a high density of double wires that will absorb the balls’ shock, so they are returned to play without delay. The Duo Sports double wire sports fencing system is developed from the Duo 6 and Duo 8 perimeter fencing systems. more...

Olympics organisers accredited 21,000 media and broadcasters to report on the greatest show on earth. They were crafting the story beamed to the estimated global audience of almost five billion tuned in to London 2012.Quite apart from keeping them safe and secure, any hint of a breach of security would have been latched upon, sending negative tales of London far and wide and damaging the city’s image and the nation’s tourist industry for years. The SolutionThe London Olympics Media Centre (LOMC) was designed by architects Allies and Morrison. It is 900,000 sq ft and 275m long and cost £355 million to build on the former Hackney Wick Stadium close to the Riverbank Arena.The main contractor Carillion asked Zaun to design, manufacture and install the 1.5km of HiSec and MultiFence security fencing with the same Super6 panels as the Olympic Park perimeter. The two high-security fencing systems use a close mesh of 6mm steel vertical wires near impossible to scale and very hard to cut through except with power tools.The fencing incorporated vehicle and pedestrian access points, as well as detection systems and CCTV. The Olympic Delivery Authority planned to create a high-security complex of business space that would form part of the legacy to the Games, recouping much of the public investment in the construction.The LOMC was part of Zaun’s Olympics contract, its largest ever, which included work on the perimeters to the Olympic Park and Stadium and temporary installations at venues across the country, all completed on time and within budget.

The Home Office and British police forces wanted a rapidly-deployed high-security temporary fencing solution that would resist forcible attack by crowds or vehicles and with no below-ground foundations to help cut the cost of policing party political conferences.The solution had to pass Hostile Vehicle Mitigation (HVM) and crowd control/mob attack testing and offer protection normally only available from permanent fixed installations. It also had to be installed and removed quickly within tight timescales.The SolutionZaun developed its RDS Fence and RDS PAS68 and then worked with the Home Office and Sussex Police to take it through testing against attack by 2.5 and 7.5-tonne vehicles to PAS68:2010 V2500 (N1G)/48/90:4.7/0.0 and PAS68:2010 V7500 (N2)/48/90:6.0/0.0 standards.RDS, which won the Security Innovation Award 2013, uniquely provides HVM up to 30mph in a rapidly deployed temporary fencing solution and was tested on- event for the first time at the European Committee of Ministers meeting.It was such a success that Sussex Police advised it was bought for the autumn party conferences, estimating a saving of 90% of police time when it was next used at the Lib Dem Conference.The Home Office initially bought 600 metres of RDS fencing, including access portals, turnstiles and gates, which was then used for the Labour and Conservative conferences that followed. It has since quadrupled the amount.RDS Fence is Secured by Design. It goes up to 3m and can include CCTV, PIDS, vehicle gates and pedestrian portals. It suits sites with moderate undulations in ground levels and differing standards of ground standings.

One of the UK’s largest utility companies required adequate security protection to their portable water sites. Water is treated from the local river supply at the site, which then supplies the local area. Therefore, it is important to ensure that the site is protected from any trespassers or any other miscreants who may be up to no good. Sites of this nature must be kept safe and secure to ensure that the water supplies to the public are kept as clean and safe as possible. The site is operated 24/7 and required additional security support to ensure the large site is kept safe and secure.Project Brief for Water Treatment Works SecurityThe site is required to be protected in line with the company Risk-Based Approach (RBA) and security requirements from DEFRA with recommended security upgrades to the physical perimeter security fencing, video surveillance systems (VSS), access control and intruder detection systems.Perimeter security fencing was required to be upgraded to at least LPS 1175 SR2 (B3) level with detection and access control and careful consideration to the surrounding forest, home to several animals, including Wild Boar. This causes several problems for the site, including damage to the existing fence and potential water quality issues. In addition, the Drinking Water Inspectorate (DWI) are particularly interested in the vermin and pest control for the site, so designing the security solution had to consider this.The SolutionBinns Security was appointed as principal contractor for CDM and project managed the whole project from start to finish, including coordinating works. Based on the site's requirements, Zaun’s HiSec Super SR2 fencing was selected to upgrade the existing non-rated perimeter fencing and gates to LPS1175 SR2 standards, providing the client with perimeter fencing system with a guaranteed delay of at least 3 minutes.Designed with a height of 2.4m as a minimum with a 358 anti-climb mesh configuration makes it very difficult to scale and prevents climbing aids. To combat vermin and pest control, the perimeterfencing is also required to be buried at 300mm, which stops the vermin and also prevents burrowing from any potential intruders.Both pedestrian and vehicular gates were also upgraded to LPS1175 SR2 to match the fence line and provide operational access without compromising the site's security. This single layered LPS1175 SR2 rated fencing system was accompanied by Harper Chalice’s perimeter intrusion detection system (PIDS) FenceSecure, which provides an early warning for any unauthorised access. Additionally, this system provided a full perimeter PID system covering fencing, gates and pedestrian access points.more...

Zaun was contracted to supply high security and anti-protestor fencing for leading fracking companies to protect their sites from trespass or intrusion by protesters.This case study investigates the fundamental role of temporary high-security fencing in protecting sites from protesters.Why was it important to protect the site?Fracking is a subject that often dominates the news and can generate heightened emotions. In addition, fracking regularly attracts protesters, resulting in the crucial necessity for site protection, such as high-security fencing.Protesters could pose a significant danger to the site's running and risk their own health if they could get onto the site.What Fencing Was Selected?Zaun installed two types of high-security temporary fencing systems to protect the site. One of these fencing systems was MultiFence temporary security fencing. Multifence is durable and mobile. In addition, concrete blocks are utilised for mounting the fencing, which can be a viable space-saving option and extremely secure and robust.The second temporary security fencing used at the fracking site was RDS Original, Zaun’s Rapid Deploy Fencing system. Why Were They Selected?Zaun’s Multifence system and RDS system are high-security solutions to temporary fencing needs. Both robust, strong and durable, they have extensive intrinsic security features that deliver the highest level of protection.Both systems have been mob tested, which means they can withstand considerable force from crowds. Thus, they are ideally suited for this purpose. Due to a lack of footholds, protesters cannot climb or scale the fence. This offers dual protection because not only does it prevent protesters from intruding onto the site, but it also significantly reduces the risk of injury to the protesters too.The Multifence and RDS systems have the potential for hostile vehicle mitigation security upgrades to the fencing if necessary. This can be crucial if there is the possibility of hostile vehicles attacking the site.As no ground penetration is necessary for installing either the Multifence or RDS, this protects the environment around the site’s perimeter. It also maintains the integrity of the site ground. They are also easily movable and redeployed over multiple sites.

The Royal Artillery Barracks in Woolwich made for a stunning venue for the London 2012 shooting competitions. But organisers knew that the ease of access and the number of roads in the area rendered the temporary shooting ranges and grandstands potentially vulnerable.Given the arsenal within, they needed a temporary perimeter that would remain intact even under deliberate attack by vehicles or people – and yet that could be removed once the Games were over with no damage to the 18th-century site.The SolutionZaun developed a mobile high-security fence with Hostile Vehicle Mitigation (HVM), especially for the London 2012 Olympics, mounting its PAS 68 Multi- Fence® into concrete blocks to resist attack by 7.5-tonne vehicles driven straight at it at 40mph.Zaun installed 2km of MultiFence and access gates around the Royal Artillery Barracks site and added HVM enhancements, detection systems and CCTV to secure the entire venue.Multi-Fence uses anti-climb mesh fencing and is available up to 5m high. The fence posts are mounted in concrete blocks that can follow a curve or go from a flat surface to an incline with ease due to an ingenious bolting method.It is one of the world’s first temporary solutions to achieve PAS68: 2010 V7500(N2) 64/90:5.0/0.0. It is manufactured to the BS EN 1317 Part 2 (vehicle restraint systems) and is approved by the Highways Agency.It is ideal for supporting crowd control at key events or for permanent installations at airports, freight terminals and ports, as no below-ground foundations are required, and they can be used on soft and hard standing.

Electricity interconnectors play a crucial role in the EU’s strategy to achieve a competitive and integrated European energy market to increase energy security and apply downward pressure to wholesale electricity prices.The 500MW EirGrid East–West Interconnector links the British and Irish markets and brings Britain’s interconnector capacity to 4GW with the 2GW IFA to France, 1GW BritNed cable to Holland and 500MW Moyle interconnector to Northern Ireland.The SolutionThe East-West Interconnector project was financed by a €300 million loan from the European Investment Bank, capital investments from commercial banks, EirGrid equity and a €110 million grant from the European Commission.With such huge sums and massive power in play, security is vital on the 47 miles of subsoil and 116 of submarine cable that connects the Woodland HVDC static inverter plant at Rush North Beach, County Meath, and the Shotton plant on Barkby Beach in North Wales.Zaun secured the two inverter plants for Irish national grid operator EirGrid with around 600 metres of ArmaWeave fencing to 3 metres in height, buried in a concrete cill and combined with a 4.6 metre high Harper Chalice electric fence, which systems integrator Crime & Fire Defence Systems installed.The fence line had to be connected to an intricate underground earthing grid and to incorporate vehicular sliding gates, pedestrian turnstiles and manual gates.ArmaWeave achieves the highest rated standards for fencing defending against forcible attacks. Its unique properties and tight mesh pattern provide no climbing aids and resist cutting attacks with hand, powered and non-contact tools.

The Olympic Delivery Authority turned to Zaun to secure the near 20km boundary of the Olympic Park. A further 1.5km of Zaun fencing provided a ‘ring-within-a- ring’ around the Olympic Stadium. Zaun worked with Olympic Park contractor Skanska and stadium contractor BAM Nuttall to install 3.6m high fencing above ground, topped with 1.2m of electric fencing, with security properties specified by Olympic security advisers.

The UK’s largest water and waste company is aiming for savings of £500,000 over the next three years in the supply and installation of security fencing and gates across its estate that supplies water to over 14 million people.However, given the risk of accidental pollution, theft and mindless vandalism, safety and security must not be compromised in making the savings across its 600 sites that supply 2,600 million litres of tap water and treat more than 4 billion litres of sewage per day.The SolutionThames Water Utilities chose Zaun as one of four appointed contractors for their three-year framework agreement for the supply and installation of security fencing and gates, with an option to renew for a further two years, worth around £2 million, and one of three for their ongoing maintenance.Thames is looking for savings and the benefits of dedicated account management, certified and experienced perimeter protection designers, engineers and technicians, access to new and innovative products and robust management reporting linked to an exacting service level agreement. Zaun proved its reputation with Thames Water during its multi-billion pound London Tideway improvements to create a cleaner healthier River Thames, on which Zaun addressed some complex planning issues and security needs. Zaun designed, manufactured and installed its ArmaWeave, the highest-rated single panel fencing solution for defending against forcible attack. This solution meets Thames’ security requirements and enables certain installation concerns to be mitigated.Zaun has also put in Axiom, turnstiles, vehicle barriers and pedestrian access control across the Thames’ estate.

The Trumpington Residents’ Association and Cambridge City Council wanted to update a 60-year-old pavilion at the heart of the village in a £600,000 community project.Cambridge architects 5th Studio designed a striking colourful exterior cladding. They turned to an artist specialising in the treatment and perimeter fencing manufacturer Zaun to create the multi-coloured stripe effect with a specialist bright green protective steel mesh ‘cage’.The SolutionTrumpington Pavilion employs an unusual multi-coloured exterior treatment. An artist specialing in the technique has dribbled green, blue, red and yellow randomly onto a corrugated plastic sandwich sheet, which is then covered with Zaun’s Duo8 mesh in bright green, fixed to coloured timber battens.The pavilion includes a main building with a hall, youth room, kitchen, toilets, office and inter-connected changing rooms for two teams plus an officials’ room.The doors to the changing rooms are in boldly contrasting colours. At the same time, an eight-metre green mesh electric sliding gate protects the building but opens to provide unrestricted access to the patio and the King George V Playing Fields beyond.Zaun installed the Diamond cantilever sliding gate with Duo8 mesh in-fill, KeyFob and internally mounted switchto ensure both the safety of all users of the pavilion when the gates are operated especially children, and the security of the contents when the pavilion is not in use.The original pavilion, built in the early 1950s, was about half the size of the new main building, including a small hall and changing rooms.

Wimbledon, the British Tennis Championships are led and conducted by the All England Lawn Tennis & Croquet Club. The championships occur every year at Wimbledon, London, in July and are well attended by tennis enthusiasts, celebrities and other spectators worldwide.The AELT&C required the venue to regularly and temporarily install tennis ball stop netting around the smaller courts around the arena to act as a ball stop fence and stop stray balls, therefore required removable fencing.The SolutionRemovable posts were designed and manufactured by Zaun’s in-house design team. The bespoke designed temporary posts were created to slot into support sockets in the ground, ensuring that the posts could be installed and removed easily for when the Wimbledon Tennis Championships are played.These removable posts were manufactured with offset holes for eyebolt type tensioners and supplied with a 30x5mm strip to thread the net through to provide a neat and tidy termination or corner. These are designed specifically to support the line wires and the netting on the additional smaller courts outside of the main court, providing a temporary ball stop netting area to stop stray balls from venturing on other courts around the venue.The removable fencing and temporary netting are installed during Wimbledon Championships and removed for the day to day running at the venue. In addition, specialist ball stop netting designed specifically for tennis courts is installed with apertures that are small enough that tennis balls cannot pass through.

Holland had to mount its largest-ever security operation when it hosted the third Nuclear Security Summit at the World Forum in The Hague in March 2014, with 13,000 police officers, 3,000 soldiers and 4,000 military police mobilized during the summit.Organisers had to guarantee the security of the world leaders from 53 countries, including event sponsor US President Barack Obama, and up to 3,000 journalists without unduly disrupting the day-to-day lives and business of local Dutch citizens.The SolutionDutch police turned to a British high-security fencing systems manufacturer with a growing international reputation as the go-to company when world leaders gather and the hosts need to guarantee their protection.Zaun installed 30km of fencing to secure the London 2012 Olympics including VIP emergency gates at the Olympic Stadium which were dubbed the Obama Gates.Last year it provided the same service for the G8 Summit in Northern Ireland and the influential meeting of global leaders and the world’s commercial, political and financial powers at the Bilderberg conference at The Grove in Watford.Zaun worked with long-term partners Hardstaff Barriers and Highway Care to design, manufacture, install and decommission the temporary high-security cordon around the summit, which included 13 gates and almost 3km of fencing, much of it designed to mitigate the attack by hostile vehicles or protesting mobs of people.Debates within the security cordon – 1.8km of SecureGuard and 1.1km of its RDS Rapid Deployable System – focused on how to lock up the world’s nuclear materials more securely so they would not be so easy for terrorists to steal: a field again where Zaun has helped in securing the nuclear industry.

The Rednock School in Dursley in Gloucestershire won the people’s choice and awards for sustainability and architectural excellence in the RIBA Regional Town & Country Awards. Wings emanate from a central red hub, designed to be energy-efficient and natural light and airy.So pioneers of transforming the ‘beacon of sustainable school design’ called in experts to design and install their planned multi-use games area (MUGA) and keep the school open while still pushing forward design boundaries.The SolutionThe 1,400-pupil school turned to artificial sports surfaces specialists AP Thompson and MUGA manufacturer Zaun to provide it with a multi-functional state of the art sports pitch.With limited space and the need to keep open throughout the works, contractors built the new school on the old playing fields then demolished the old buildings to make way for the new MUGA.Zaun recommended its Duo6 Sports fencing with fixings every 200mm instead of 400mm. Each fixing point uses a rubber EPDM insert that insulates the panel from the post and reduces rattle during play to a minimum. This is a solution Zaun has developed for schools to minimise noise from outdoor pitches distracting classes being taught indoors.Clever siting of goal recesses makes the MUGA ideal for a full size international standard football pitch or four concurrent 5 a side matches across the width. In addition, Zaun incorporated gates at strategic locations and 4.4m high fencing behind the goal areas to improve ball retention.After four decades, the reincarnation of the school cost £38 million in total and includes a TV studio able to broadcast live to every corner of the school.

Leading English National Premier League side Cannock Hockey Club were fed up with the high maintenance costs of replacing nets and wooden boards damaged by constant ball impacts.So they wanted lower maintenance perimeter fencing when they upgraded their pitches in 2009 – and ideally to limit the noise of the wooden boards under constant impact from 5.5oz balls travelling at speeds in excess of 80mph which was affecting the experience for players and spectators alike.The SolutionFounded in 1905, ‘The Nockers’ is one of the most successful National Premier League hockey clubs in the country, having won the title seven times since the league’s inception 25 seasons ago.But their traditional wooden perimeter boards were effectively sacrificial under hockey’s cannonball-like impacts. As they quickly broke and got worn out, the club was in a constant and expensive cycle of buying and installing new ones.The grounds committee turned to Zaun as a development partner to create a ground-breaking low-noise and -maintenance metal fence perimeter.It replaces nets and wooden boards with twin wire mesh fencing. Fixings every 200mm and rubber EPDM inserts at each fixing virtually eliminate rattle during play.The bottom 210mm – or up to 400mm behind the goals – uses twin horizontal 8mm wires in a close 25x50mm mesh pattern that reduces significantly the noise while withstanding a far greater number of ball impacts without damage.The system is then topped with Zaun’s Super Rebound, which gives better viewing, no risk of player or spectator injury from splinters or mid-rails and no solid surface for vandals to graffiti.
