Budget Firepan Double Door 2 hr Fire Rated Access Panel

Name: Budget Firepan Double Door 2 hr Fire Rated Access Panel
Brand: Access Building Products Ltd
SKU: t8mFZAixQ5WmA56Rv2NEQg

Verified by manufacturer 4 months ago

Access Building Products Ltd

Third party certifications:

Warringtonfire
Certificate type

Double door access panel, 2 hours fire rated.

Jump to:

+44 (0)1423 874753 Website

Application

Wall mounted access panel.

Description

The Firepan Double Door access panel designed for wall use has been subjected to a rigorous fire test and achieved a fire rating of up to 120 minutes. It is available in customized sizes, with the maximum dimensions being H: 2000 x W: 1300 mm. Additionally, it offers an acoustic reduction of 36 dB.

Features and benefits:

Fire test in accordance with BS 476: Part 22: 1987 standards up to 120 minutes.
Tailor-made to any size up to maximum dimensions being H: 2000 x W: 1300 mm.
Manufactured from Zintec steel.
An acoustic reduction of 36 dB.

General information

Color	White
Finish	Powder-coated
Material	Zintec steel
Shape	Square Rectangle
Length	2000 mm Guidance for specification option: Maximum length. Bespoke
Width	1300 mm Guidance for specification option: Maximum width. Bespoke
Height	50 mm
Warranty description	Two year

Uniclass	Pr_30_59_36_01 Access panelsPrimary
CAWS	L20/60 Doors L20/630 Hatches K10/430 Access panels

Specification data - Access panels

Fire performance	-
Fire resistance	120 minutes to BS 476-22.
Position	Wall-mounted.
Size	Guidance for specification option: Made to order. Consult manufacturer and insert requirements. Maximum dimensions: H: 2000 x W: 1300 mm. Manufacturer guidance When fitting the panel, it is recommend allowing an additional 10 mm beyond the panel size when creating the structural opening. This extra space facilitates the fitting and alignment of the frame. The doors can be easily removed to assist in the installation process. Moreover, the inner frame is supplied with pre-punched fixing holes, enabling quick and straightforward screw-fixing of the panel.
Frame	Exposed picture frame type. Bead for taping and jointing.
Panel	-
Material	Steel. Guidance for specification option: Zintec steel.
Integral finish	Powder-coated.
Latch or lock type	Budget lock. Guidance for specification option: Standard. Operated using a steel "T" key. The primary door features a lock aperture on the face, enabling a 3-way lock mechanism that secures the door in three different places. The secondary door is secured at the top and bottom edges and can be operated from the back of the door. Tamper-proof lock. Guidance for specification option: Available on request. Euro-profile lock. Guidance for specification option: Available on request.
Operation	Concealed steel hinges, outward opening. Guidance for specification option: Each fire-rated door is equipped with a full-length concealed piano hinge, ensuring a secure installation. The door is fastened to the hinge using hex-nuts, allowing for easy removal if necessary.
Integral accessories	Guidance for specification option: Consult manufacturer and insert requirements or omit.

Colour	Traffic white, RAL 9016.
Depth	50 mm. Manufacturer guidance Panel.
FrameThickness	25 mm.
Sound reduction	36 dB.

Sustainability data

Contains Red List materials	No
Country of material origin	United Kingdom
Country of product manufacture	United Kingdom
Recyclability	Steel 100%
Recycled content As defined in clause 7.8 of BS EN ISO 14021	40 %
