E77 Elite SR2 Extruded Aluminium Security Shutter

Name: E77 Elite SR2 Extruded Aluminium Security Shutter
Brand: Roché Systems Ltd
SKU: 7mzBcbQxzofZPiH9BH11B3

Verified by manufacturer 7 days ago

Roché Systems Ltd

Third party certifications:

Secured By Design
Certificate type
QA Certificate
Certificate type

LPCB SR2 insurance approved extruded aluminium security roller shutters with 77 mm high slats.

Jump to:

BOS

03330347967 Website

Application

Suitable for commercial sites and shopfronts that require high security.

Description

Extruded aluminium security roller shutters with 77 mm high slats and designed to suit specific site requirements. Features and benefits: Tested by the Loss Prevention Certification Board (LPCB) to LPS 1175 SR2 and awarded insurance approved 'Secured by Design' status. Mounted internally, externally or reveal fixed. Span up to 5 m in width and an area up to 25 m². Available with solid and punched profiles.

Features and benefits:

Guide channel depth: 150 mm.
Weight: 8.5kg/m².

General information

Color	White Brown Manufacturer guidance Option to powder coat any RAL / BS colour or laminate wood effect (surcharge applies). Please consult manufacturer and insert requirements.
Finish	Galvanized Powder-coated Plastisol
Material	Aluminium
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	One year

Uniclass	Pr_30_59_84_73 Roller shuttersPrimary
CAWS	L20/60 Doors L20/610 Roller shutters/ curtains

Product range	Extruded Roller Shutters

Specification data - Roller shutters

Opening sizes	5000 x 4000 mm. Guidance for specification option: Available up to 5000 x 4000 mm (w x h). Up to 25m². Manufacturer guidance Enclosure size (internal face fix): Dependent on height. <2700 mm: 300 mm. 2700–3640 mm: 360 mm. 3640–4600 mm: 400 mm.
Arrangement	Vertical, external face fix. Vertical, internal face fix. Vertical, reveal fix.
Shutter curtain.	-
Lath material	18.5 mm thick solid double skinned extruded aluminium, 77 mm in height.
Profile	77 mm.
Finish and colour	Brown. Guidance for specification option: Standard colour. White. Guidance for specification option: Standard colour. BS. Guidance for specification option: Insert colour requirement. RAL. Guidance for specification option: Insert colour requirement.
Frame and guides	-
Material	Enclosure: Roll formed aluminium box with pressure-moulded aluminium alloy end caps. Guide channels: 150 mm deep heavy duty extruded aluminium. To comply with LPCB certification, the channels must be installed 30 mm from the opening, allowing 180 mm from the opening edge to the back of the guide channels. Bottom slat: Extruded aluminium with brush and rubber weather seals.
Colour	Brown. Guidance for specification option: Standard colour. White. Guidance for specification option: Standard colour. BS. Guidance for specification option: Insert colour requirement. RAL. Guidance for specification option: Insert colour requirement.
Operation	-
Mode	Somfy Electric Single Phase (Tubular Motor) with safety brake. Manufacturer guidance Single phase tubular motor with internal rocker or external key switch. Numerous control option variants such as group, remote or mobile phone activation are available.
Control	Somfy tubular motor & internal rocker or external key switch as standard. NRG tubular motor & internal rocker or external key switch as standard.
Accessories	None. Crank handle. Manual override facility. Polycarbonate infills. Guidance for specification option: Available with V77 only, must be used to achieve SR2 rating.
