Kydex® XD03 Thermoplastic PVC/ Acrylic Pearlescent Sheet - Acrylic sheet
Verified by manufacturer 6 months ago
Thermoplastic 3D laminate with integral pearlescent colour.
Application
Suitable for:
- Store fixtures.
- Kiosks.
- Checkout counters.
- Cabinetry.
- Exhibits and displays.
- Door and drawer fascias.
- Mouldings.
- Pedestals and stands.
- Transaction surfaces.
- Workstations.
- Tabletops.
- Logo and trademark panels.
- Wainscots.
- Flat laminated panels.
Description
A high performance thermoplastic sheet with integral pearlescent colour, specifically formulated to provide an attractive aesthetic effect for the design needs of the building and retail interiors industry.
Features and benefits:
- Tough and durable.
- Resistant to cracking and chipping.
- Solid, integral colour.
- Available in 20 colours.
- Resistant to a wide range of chemicals.
- Abrasion resistant.
- Fire retardant.
- Very low moisture absorption.
- Flexibility allows small radius bends.
- Linear glass scratch resistance (to NEMA LD3): <50 g.
- Diamond scratch resistance (to NEMA LD3): 3.
- Ball impact resistance (to NEMA LD3): >3000 mm.
- Dart impact resistance (to NEMA LD3): >1075 mm.
- Surface spread of flame (to ASTM E-84): Class 1/A.
General information
Shape | Rectangle |
Length | 3048 mm |
Width | 1447 mm |
Uniclass | |
CAWS | K13/140 Proprietary laminated plastics-veneered panel lining K30/10 Relocatable partition system K30/130 Relocatable partition system K32/112 Fully framed panel cubicles K32/120 Panel cubicles K32/130 Privacy screens K32/140 Duct/ wall linings – panels only K32/150 Duct/ wall linings – panels and proprietary frames K32/160 Duct linings – preplumbed panels and proprietary frames N10/10 Purpose-made N10/110 Purpose-made N10/160 Shelving systems N10/30 Shelving systems N11/380 Purpose-made units N12/440 Purpose-made |
Specification data - Compact or solid grade high-pressure laminate (HPL) boards
Thickness | 0.7 mm. |
Panel size | |
Length | 3048 mm. |
Width | 1447 mm. |
Colour | Guidance for specification option: Insert requirement, consult manufacturer for information. |
Grades | Extreme durability (XD). |
Texture | PK. |
