M2M+ Single Leaf Steel Doorset with Optional Fire Rating - Bespoke Steel Doorset

Name: M2M+ Single Leaf Steel Doorset with Optional Fire Rating - Bespoke Steel Doorset
Brand: Bradbury Group
SKU: 9TgB441T36UAz1MCx7NiEx

Verified by manufacturer 3 months ago

Bradbury Group

Third party certifications:

EN 13501-1 (Efectis)
Certificate type
Al Futtaim Element
Certificate type
Certifire Certificate
Certificate type
BRE Certificate
Certificate type

Multi-purpose, single-leaf steel doorsets with optional acoustic and/or internal fire rating.

Jump to:

BOS

+44 1724 275720 Website

Application

Suitable for for internal or external installation in industrial, commercial, and domestic buildings.

Description

Versatile steel door sets for internal or external installation in industrial, commercial, and even domestic buildings. M2M⁺ doors are bespoke-engineered in-house, allowing for a wide scope of locking options to be integrated into the doorsets, to suit each specification.

Features and benefits:

Multi-purpose.
Single-leaf configuration.
Bespoke, engineered in-house.
Polyester powder coated in a selection of colours and finishes.
High quality wood grain effect available.
Wide range of locking options available.
Patented adjuster system and fast-fit frame available.
Constructed from zintec steel, stainless steel, or magnelis.
Side and/ or over panels available.
Hinged or removable over panel available.
Range of vision panels and louvres available.
Optional ISO 10140 acoustic rating from Rw 28 to Rw 40.
Internal Fire Rated door available up to FD240.

General information

Color	Other Beige Black Blue Bronze Brown Cream Green Grey Ivory Orange Pink Purple Red Turquoise White Yellow Show more
Finish	Powder-coated
Material	Steel Zintec steel Stainless steel
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	One year

Uniclass	Pr_30_59_24_52 Carbon steel doorsetsPrimary
CAWS	L20/55 Doorsets L20/480 Doorsets

Specification data - Carbon steel doorsets

Configuration	Single-leaf, single-action, outward opening. Single-leaf, single-action, inward opening.
Doorset size	Guidance for specification option: Insert requirement. Single outward opening doorsets: Height: 1750 mm (minimum); 2950 mm (maximum). Width: 300 mm (minimum); 1470 mm (maximum). Single inward opening doorsets: Height: 1775 mm (minimum); 2950 mm (maximum). Width: 300 mm (minimum); 1470 mm (maximum).
Performance	-
Fire resistance	-
Integrity	Not required. Up to FD 240. Guidance for specification option: Integrity fire resistance for up to 240 minutes, certified by Exova under the CERTIFIRE scheme (certificate number CF5108). Consult manufacturer for details.
Acoustic performance	Unrated. To BS EN ISO 10140-2, sound reduction index Rw 28 dB minimum. Guidance for specification option: Tested by Lorient to BS EN ISO 101402: 2010. Certain M2M+ doors are available with acoustic ratings from Rw 28 to Rw 40, providing 28 dB to 40 dB of noise reduction, depending on specification. Consult manufacturer for details.
Thermal	1.6 W/m²K. Guidance for specification option: Non-fire rated and without visions and louvres. Unrated.
Frame	-
Material	Zintec steel. Stainless steel. Magnelis. Manufacturer guidance Frame thickness: 1.5 mm.
Threshold	Steel. Aluminium
Finish	-
Coating	Polyester powder-coated. Guidance for specification option: As standard. Wood effect. Guidance for specification option: Optional finish available at an extra cost.
Texture	- Manufacturer guidance Consult manufacturer and insert requirement.
Colour	- Manufacturer guidance Consult manufacturer and insert requirement.
Installation fasteners	Seven dog bolts per leaf (minimum).
Frame accessories	Butt jointed frame sections. Guidance for specification option: As standard. Fully welded frame. Guidance for specification option: Optional - available at an extra cost.
Door leaf	-
Thickness	45 mm.
Material	Zintec steel, 1.2 mm thick. Stainless steel 1.2 mm thick. Zintec steel, 1.5 mm thick. Stainless steel, 1.5 mm thick. Magnelis, 1.5 mm thick.
Glazing	-
Type	Not required. Vision panel, 203 x 356 mm. Vision panel, 203 x 762 mm. Vision panel, 457 x 457 mm.
Beading	-
Type	10 mm astragal.
Material	Steel.
Fixing	- Manufacturer guidance Consult manufacturer and insert requirement.
Finish	-
Coating	Polyester powder-coated. Guidance for specification option: As standard. Wood effect. Guidance for specification option: Optional finish available at an extra cost.
Texture	- Manufacturer guidance Consult manufacturer and insert requirement.
External colour	- Manufacturer guidance Consult manufacturer and insert requirement.
Internal colour	As External. Other. Guidance for specification option: Consult manufacturer and insert requirement.
Hardware	Not required. Stays and closers, Dorma TS72. Stays and closers, Dorma TS83. Stays and closers, Briton 2130. Stays and closers, Geze TS4000.

Sill	Not required. Steel sill. Aluminium sill.
Door frame profile	90 mm deep. Guidance for specification option: Standard. 150 mm deep. Guidance for specification option: Optional.
Locking	Union deadlock Union sashlock. Emergency escape sashlock. 5 level deadlock. MICO rimlock. Union night latch. Codelock series no. 525 with lever handle (pair). Borg keypad series no. 5401. 4 point locking. Trimec electric strike and union night latch. 272 kg magnetic locks. Solenoid bolts. Show more
Panic hardware	Not required. Briton 1438E push pad with single point latch. Briton 378E single point panic bar. Briton 378E 2 point vertical bars. Briton 376E and 378E 3 point panic bar. CORNI single point locking panic latch. CORNI 3 point locking panic latch. CORNI 5 point panic hardware. Show more
Louvre panels	Not required. Punched louvre cartridges. Bladed louvre cartridges. Manufacturer guidance Louvres must be fire rated, and will decrease the fire rating to FD240.
Over/ side panels	Not required. Fixed side panels. Fixed over panels. Removable over panels. Hinged over panel. Guidance for specification option: Doors fitted with hinged or removable over panels are not fire rated.
Weight	45 kg/m². Manufacturer guidance Circa.
