RDS Rapid Deploy Free-Standing HVM Fencing System
Verified by manufacturer 9 days ago
RDS is a foundation-free, rapid deploy HVM fencing system crash tested to PAS 68, providing temporary full-height vehicle mitigation and perimeter security without ground pinning.
Application
RDS is suitable for:
- Major sporting events
- Political conferences and summits
- State visits
- Temporary urban security zones
- Infrastructure works
- Crowd management perimeters
- Sites requiring rapid deploy HVM
Description
RDS is a rapid deploy, free-standing Hostile Vehicle Mitigation (HVM) fencing system designed to provide temporary vehicle impact protection and perimeter security without foundations or ground pinning.
The system comprises 358 welded mesh fence panels and posts mounted into engineered RDS concrete blocks, allowing full-height deployment from ground level to panel top. Installation and removal can be completed within minutes, minimising site disruption.
RDS is independently crash tested to PAS 68:2010 and IWA 14-1 standards, achieving classifications including:
- V/2500 (N1G)/48/90:4.7/0.0
- V/7500 (N2)/48/90:11.6/0.0
The system provides multi-threat mitigation, combining hostile vehicle resistance with anti-climb welded mesh to deter intrusion.
RDS can incorporate integrated vehicle and pedestrian gates, CCTV, perimeter intrusion detection systems and security toppings. It is suitable for both temporary event overlay and semi-permanent installations where below-ground foundations are not feasible.
Key Features and Benefits
- Foundation-free temporary HVM fencing
- No ground pinning or excavation required
- Crash tested to PAS 68:2010
- Tested to IWA 14-1 for integrated gate configurations
- Stops 2.5 t and 7.5 t vehicles at tested speeds
- Full-height free-standing system
- Rapid deployment and redeployment
- Minimal site disruption
- Anti-climb 358 welded mesh panels
- Compatible with CCTV and PIDs
- Integrated vehicle and pedestrian access solutions
- Suitable for hard and soft ground standings
- Available for purchase or rental
- Lightweight variant available
General information
Finish | Galvanized Powder-coated |
Material | Metal |
Width | 2900 mm |
Height | 2438 mm 2702 mm |
CAWS | Q40/125 Open mesh steel panel general-purpose fencing Q40/126 Open mesh steel panel security fencing Q40/27 Open mesh steel panel general-purpose fencing Q40/30 Proprietary fencing Q40/430 Proprietary fencing |
Specification data
Classification data | |
Panel/ mesh type | HiSec 358 mesh. Guidance for specification option: 76.2 mm x 12.7 mm pattern. With 4 mm vertical and horizontal wires. Others are available - consult manufacturer for information. |
Height | 1800—3000 mm. Manufacturer guidanceConsult manufacturer and insert requirements. |
Colour | Guidance for specification option: Insert RAL colour requirement. |
Gates | 50 x 50 mm rectangular hollow section (RHS) frame with Zaun HiSec mesh bolted onto the frame, slide latch, rubber bump stop, two gate posts. Guidance for specification option: Vehicular gates also include drop bolts. |
Accessories/ Other requirements | Not required. CCTV cameras. PAS 68 enhancements. Perimeter Intrusion Detection Systems (PIDs). Topping enhancements. Pedestrian gates. Guidance for specification option: Single leaf, 1.2 m wide, or width to suit, consult manufacturer and insert requirements. Vehicular gates. Guidance for specification option: Single or double leaf, 3.0 m wide, or width to suit, consult manufacturer and insert requirements. |
Finish: | Galvanized and polyester powder-coated (PPC). |
Posts | 70 x 70 mm rectangular hollow section (RHS) posts. |
Post centres | 2750 mm. |
Panel fixings | Panels fixed to posts with full height 40 mm x 5 mm clamp bar, with through bolt fixings at 400 mm centres. |
Base size (l x w x h) | 900 x 450 x 800 mm. Manufacturer guidanceConcrete base size. |
Weight | 750 kg. Manufacturer guidanceConcrete base weight. |
Width | 2900 mm. |
Standards | To BS EN 10244-2. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Manufacturing plant location | |
Material | Metal |
Recyclability | All fencing systems are 100% recyclanle at end of life |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 80 % |
Expected Life | 25 year |
