Record THERMCORD RC3 Burglar Resistant Automatic Door

Name: Record THERMCORD RC3 Burglar Resistant Automatic Door
Brand: Record U.K. Limited
SKU: urR3qmg6ZhrUL1LQtbQbNq

Verified by manufacturer 28 days ago

Record U.K. Limited

Third party certifications:

Achilles Information Limited - Procurement Management
Certificate type
ADSA
Certificate type
ISO 14001 Environmental Management Systems
Certificate type
ISO 45001 Health and Safety Management
Certificate type
ISO 9001 Quality Management
Certificate type
CHAS
Certificate type
Alcumus SafeContractor
Certificate type
Constructionline Gold
Certificate type
QA Certificate
Certificate type

Door system with thermally separated energy saving properties and burglar resistances.

Jump to:

+44 (0)1698 376411 Website

Application

Suitable for escape and rescue route applications.
Suitable for exterior doors and offers protection from cold or heat loss, as well as to ward off burglary attempts.
Suitable for shop, hotel or office building entrance doors.

Description

The Record THERMCORD RC3 burglar resistant automatic door offers intruder protection with efficient, energy-saving properties reducing heating costs.

These intruder protection doors are suitable for hotels, office buildings or any shops that hold high value merchandise or equipment and are also suitable for fire escape and rescue routes.

These doors are thermally separated by creating a seal when the door is closed, they eliminate any permanent outflow of heat and prevent air pollution from entering the building.

These energy saving doors are ideal for entrances that require burglar protection with special constructive measures, stiffeners and reinforced elements, which are integrated into the door system, to provide effective protection against intruders.

For increased burglar protection these doors feature a multi-point locking system MPV as standard in addition to the sophisticated reinforcements of an electro-mechanical locking unit and improved transmission gear, to protect against manipulation.

The drives in the Record THERMCORD RC2/RC3 burglar resistant automatic door are incredibly reliable and have proven their worth thousands of times.

Features and benefits:

Effective burglar resistance in combination with efficient energy-saving properties that reduce energy costs.
Panel profile thermally separated.
Reinforced door leaves and vertical profile for increased security.
Electronic multi-point locking (MPV) as standard, for convenient locking at the touch of a button.
Burglar-resistant safety glass of class P5A according to EN 356.
CNS floor rail with continuous centre-board.
Conformity to EN 16005, DIN 18650 and EN 16361 standards.
RC 3 according to EN 1627 for increased safety.
Maximum speed 0.75 m/s.

General information

Color	Silver Other Guidance for specification option: Any RAL or Eloxal colour. Clear Beige Black Blue Bronze Brown Copper Cream Gold Grey Green Ivory Orange Pink Purple Red Turquoise White Yellow Show more
Finish	Anodized
Material	Glass Steel
Shape	Rectangle
Width	Bespoke
Height	Bespoke
Warranty description	One year

Uniclass	Pr_30_59_24_80 Sliding door and partition setsPrimary
CAWS	L20/490 Automatic doors L20/280 Doors L20/480 Doorsets L20/520 Sliding doors L20/55 Doorsets

Specification data - Sliding door and partition sets

Performance	External, insulated, burglar resistant.
Arrangement	RC 2, single, bottom-rolling.
Track system	CNS floor rail with continuous centre-board.
Door leaves	-
Construction	Burglar-resistant safety glass (reinforced), class P5A to EN 356.
Operation	Powered.
Hardware	Electronic multi-point locking (MPV). Guidance for specification option: As standard. An electro-mechanical locking unit with an improved transmission gear is located in the drive housing to protect against manipulation. Leaf reinforcements. Guidance for specification option: Two rods running longitudinally through the door, which are completely integrated into the door leaf, are lowered several centimetres deep into the holes provided in the floor rail. The parts used are all made of stainless steel and have the necessary strength to prevent forced entry as far as possible.

Opening width	800–2500 mm. Manufacturer guidance Maximum door leaf size dependent on glass type and wind load, consult manufacturer and insert requirement.
Passage height	3000 mm (maximum). Guidance for specification option: Maximum door leaf size dependent on glass type and wind load, consult manufacturer and insert requirement.
Beam length	2 x opening width + 125 mm.
Drive unit	210 x 150 mm. Guidance for specification option: With cladding, with and without side screen available. 157 x 150 mm. Guidance for specification option: Without cladding and side screen. 210 x 200 mm. Guidance for specification option: With cladding, with and without side screen available. Suitable for escape and rescue routes, with reduced wind load limit. 167 x 200 mm. Guidance for specification option: Without cladding and side screen. Suitable for escape and rescue routes, with reduced wind load limit.
RatedVoltage	100–240 V a.c. (50/ 60 Hz).
Power	90 W (rated), 25 W (approximate consumption in idle mode).
TemperatureRange	-15 to +50°C.
RelativeHumidity	Up to 85%, no condensation.
Opening speed	0.75 m/s (maximum).
MotorDriveType	Gear belt with worm gearbox.
Power	200 W (maximum).
