SupaLite Tiled Roof Systems - Conservatory Roof System
Verified by manufacturer 10 days ago
The SupaLite roof uses a lightweight, aluminium frame, 185 mm of humidity-proof insulation, a waterproof membrane and sturdy tiles to create a resilient conservatory that can withstand any weather.
Application
Tiled roof system suitable for replacement conservatory roofs, extensions or new build applications.
Description
The SupaLite roof uses a lightweight, aluminium frame, 185 mm of humidity-proof insulation, a waterproof membrane and sturdy tiles to create a resilient conservatory that can withstand any weather.
Features and benefits:
- Saves money on heating costs; keeps conservatories cool on sunny days, even in direct sunlight.
- U-value of 0.15 W/m²K as standard; optional 0.12 W/m²K available.
- Meets all Building Regulation requirements.
- Transforms a conservatory into an extension.
- Adds value to the property.
- Increases living and entertaining space.
- Extra security and peace of mind as tiles can withstand attempted removal.
- Prevents any leaks with watertight installation.
- Minimizes noise from rain, wind and wildlife.
- Eliminates most glare experienced with polycarbonate or glass roofs.
- Virtually maintenance free, reducing the need to climb ladders to clean dirty roofs.
- Is designed and tested to standards demanded by Building Control.
- Quick to install, meaning less time and disruption on site.
General information
Material | Aluminium PVC-U Polyisocyanurate (PIR) Plywood Slate |
Shape | Rectangle Square Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | B12/5 Conservatory B12/120 Conservatory |
Specification data - Glazed enclosures
Performance criteria | Manufacturer guidanceInsert requirements. See also System U-value below for related options. |
External size | |
Length | Guidance for specification option: Insert requirements, refer to drawing/ design or schedule as required. |
Width | Guidance for specification option: Insert requirements, refer to drawing/ design or schedule as required. |
Height | Guidance for specification option: Insert requirements, refer to drawing/ design or schedule as required. |
Style | Edwardian.P-shape.Victorian 5 bay.Victorian wide front.Victorian. |
Roof | |
Frame | |
Material | Aluminium ridge beam/ hip beams/ eaves beams. |
Finish | Manufacturer's standard. |
Colour | Manufacturer's standard. |
Ventilation | |
Purge | None.Roof windows.Guidance for specification option: The internal colour options are white or pine as standard. Ventilation system.Guidance for specification option: Integrated ventilation components to maintain airflow and prevent condensation. Roof vents.Guidance for specification option: Optional ventilation units integrated into the roof to improve air circulation. |
Rainwater drainage | PVC-U guttering and downpipes.Guidance for specification option: System for managing rainwater runoff, ensuring proper drainage from the roof. |
Flashings | |
Location | To be determined by installer. |
Material | Lead. |
Accessories | None.SkyVista solar control glass panels.Guidance for specification option: Optional skylights integrated into the roof for natural light and a modern aesthetic. External soffit LED lights.Guidance for specification option: External LEDs, fitted into the soffit. Consult manufacturer for details. Internal three-step dimmable LED lights.Guidance for specification option: LED ceiling lights, can be fitted in the ridge bulkhead or a pelmet closer to the eaves beam. Ridge support beam.Guidance for specification option: When the deflections exceed an acceptable level, it is necessary to brace the structure with an additional support, namely a tie bar or ridge support beam. Coloured fascias and soffits.Guidance for specification option: Insert requirements. Can be made to match the existing property aesthetics, including most colour options. It also accommodates external soffit lights. Tie bars.Guidance for specification option: Steel bars providing additional structural support to prevent roof spread. Gallows brackets/ box gutter supports.Guidance for specification option: Support brackets for box gutters, ensuring stability over longer spans. Manufacturer guidanceConsult manufacturer for details as required. See also Ventilation for specific accessories. |
Tiles | ExtraLight lightweight tiles, Charcoal V2. ExtraLight lightweight tiles, Ember V2. ExtraLight lightweight tiles, Walnut V2. Composite slate, black. Composite slate, grey. |
Insulation | Guidance for specification option: High-performance insulation for thermal efficiency, fitted between rafters. Consult manufacturer for options and insert requirements. |
System U-value | 0.15 W/m²K. Guidance for specification option: Standard. ≥0.12 W/m²K. Guidance for specification option: Consult manufacturer for details. |
Integral accessories | Plywood/ OSB sheeting. Guidance for specification option:
|
Membrane | Breathable membrane. Guidance for specification option: Water-resistant but breathable layer that prevents moisture ingress while allowing ventilation. |
Fascia | Fascia boards. Guidance for specification option: Boards installed along roof edges, supporting guttering and enhancing appearance. Manufacturer guidanceSee also Accessories for lighting options. |
Supports | Structural posts. Guidance for specification option: Vertical support elements transferring roof loads directly to the foundation or dwarf walls. |
Internal linings | Insulated plasterboard. Guidance for specification option: Interior ceiling finish. PIR insulation attached to plasterboard. Smooth, paintable surface. |
Sustainability data
Material | Aluminium PVC-U Polyisocyanurate (PIR) Plywood Slate |
