Legacy Cast Aluminium Moulded No.46 Ogee Gutter

Name: Legacy Cast Aluminium Moulded No.46 Ogee Gutter
Brand: Aluminium Roofline Products Ltd
SKU: x1c4BsKAycVVk4kEWKsi7V

Verified by manufacturer 19 days ago

100 mm - Left hand system

Aluminium Roofline Products Ltd

A range of ogee gutters, manufactured from cast aluminium.

Jump to:

+44 (0)116 289 4400 Website

Application

Suitable for new build and refurbishment applications.

Description

Legacy cast aluminium Moulded No. 46 Ogee gutters are available in various sizes and are supplied with a complete range of accessories, such as angles, outlets, stopends and brackets.

100 x 75 mm and 125 x 100 mm ranges are left hand systems; 150 x 100 mm range is a right hand system. True and faceted radius gutters are also available.

Cast aluminium gutters have become the widely accepted alternative to Cast Iron and are now a first choice owing to their lightweight, corrosion resistant, low maintenance and aesthetically pleasing characteristics.

Features and benefits:

Made from aluminium alloy LM6 to BS 5750:2008.
Radius gutters - True or faceted radius available.
Other profiles available.
Supplied mill finished (uncoated) or polyester powder-coated in RAL or BS standard colours.

General information

Color	Black Other
Finish	Mill Powder-coated
Material	Aluminium
Shape	Other
Length	1830 mm
Width	100 mm 125 mm 150 mm
Height	75 mm 100 mm

Uniclass	Pr_65_50_35_06 Aluminium eaves guttersPrimary
CAWS	R10/11 Aluminium gutters R10/311 Aluminium gutters

Specification data - Aluminium eaves gutters

Form	Cast.
Profile	Ogee.
Size (nominal width)	100 mm.
Finish	Mill. Powder coating.
Colour	- Manufacturer guidance Polyester powder-coating is available in RAL or BS standard colours. Consult manufacturer and insert requirements.
Integral accessories	43CMOAX90 - 90° External Angle. 43CMOAI90 - 90° Internal Angle. 43CMOAX135 - 135° External Angle. 43CMOAI135 - 135° Internal Angle. 43CMOO2R - Running Outlet (Ø63 mm). 43CMOO3R - Running Outlet (Ø76 mm). 43CMOO3S - Running Outlet (76 x 76 mm). 43CMOO43 - Running Outlet (101 x 76 mm). 43CMOSEI - Internal Stopend. 43CMOSEX - External Stopend. 4CVOUC - Union Connector. 43CMOBDF - Direct Fix Wedge. 43CMOBF - Fascia Bracket. 43CMOBRT - Top Fix Rafter Bracket. 43CMOBRS - Side Fix Rafter Bracket. 43CMOBRF - Rise and Fall Bracket.
