Sentinel Extruded Aluminium Modern Ogee Gutter
Verified by manufacturer 19 days ago
A range of ogee gutters, manufactured from extruded aluminium.
Application
- Suitable for new build and refurbishment applications.
- Schools and commercial buildings.
Description
Sentinel extruded aluminium Modern Ogee gutter range is available in various sizes and is supplied with a complete range of accessories such as angles, outlets, and stop ends. Please note ARP do not offer brackets for this system as it is a direct fix option only.
Extruded aluminium gutters are suitable for new build and refurbishment applications due to their smooth lines, clean appearance and robust properties. This large profile can collect a considerable amount of rainwater run off and provide drainage for the largest all pitched roofs, like school and commercial buildings.
Features and benefits:
- Made from aluminium alloy 6063 T6 and LM6.
- 100% recyclable, lightweight and strong.
- Radius gutters - Faceted radius available.
- Other profiles available.
- Supplied mill finished (uncoated) or polyester powder-coated in RAL or BS standard colours.
General information
Color | Black Other |
Finish | Mill Powder-coated |
Material | Aluminium |
Shape | Other |
Length | 3000 mm 2500 mm 2000 mm 1000 mm 500 mm |
Width | 200 mm |
Height | 150 mm |
Uniclass | |
CAWS | R10/11 Aluminium gutters R10/311 Aluminium gutters |
Specification data - Aluminium eaves gutters
Form | Extruded with cast fittings. |
Profile | Ogee. |
Size (nominal width) | 200 mm. |
Finish | Mill.Powder coating. |
Colour | Manufacturer guidancePolyester powder-coating is available in RAL or BS standard colours. Consult manufacturer and insert requirements. |
Integral accessories | 86MOAX90 - 90° External Angle.86MOAI90 - 90° Internal Angle.86MOAX135 - 135° External Angle.86MOAI135 - 135° Internal Angle.86MOO2R - Running Outlet (Ø63 mm).86MOO3R - Running Outlet (Ø76 mm).86MOO4R - Running Outlet (Ø101 mm).86MOO2S - Running Outlet (63 x 63 mm).86MOO3S - Running Outlet (76 x 76 mm).86MOO43 - Running Outlet (101 x 76 mm).86MOO4S - Running Outlet (101 x 101 mm).86MOSER - Stopend (RH).86MOSEL - Stopend (LH).86MOUC - Union Connector. |
Length | 86MOG3 - 3000 mm. 86MOG2.5 - 2500 mm. 86MOG2 - 2000 mm. 86MOG1 - 1000 mm. 86MOG0.5 - 500 mm. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Material | Aluminium |
Manufacturing plant location | |
Recyclability | 100% recyclable |
Expected Life | 30 year |
Literature
Sentinel Modern Ogee Data Sheet
Technical Product Guide - Sentinel
