Promat SUPALUX® - Self Supporting Ceilings - CL SLUX-EI30-021S

Name: Promat SUPALUX® - Self Supporting Ceilings - CL SLUX-EI30-021S
Brand: Promat UK
SKU: 41FYtXAzWYPgrNrzSLyrf5

Verified by manufacturer 6 days ago

Promat UK

Product certifications:

EPD
Certificate type

Reinforced calcium silicate board for self supporting ceiling systems.

Jump to:

0800 145 6033 Website

Application

Suitable for use in self supporting ceiling systems.

Description

Promat SUPALUX® is a non-combustible calcium silicate board reinforced with selected fibres and fillers, is resistant to the effects of moisture and will not be subject to physical or performance deterioration when used in damp or humid conditions. The strong rigid board can be installed before the building is watertight, making it especially suitable in semi-exposed applications such as carparks or plantrooms. It is classified A1 non-combustible according to BS EN 13501-1.

Promat SUPALUX® is off-white in colour and has a smooth finish on one face with an embossed reverse face, it can be left undecorated or easily finished with paint.

General information

Color	White
Finish	Smooth Embossed
Material	Calcium silicate
Shape	Rectangle
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	- Manufacturer guidance Etex Building Performance Limited warrants that its products and component parts shall be durable and free from defects due to faulty manufacturing or factory workmanship. Etex Building Performance Limited also warrants that, when combined to form a system as detailed in the Project Pack specification document including associated CAD drawings and any other specific technical recommendations made in relation to this project, will meet the specified system performance. The full details of this warranty are covered in the Promat Warranty Document, available upon request.

Uniclass	Ss_30_25_10_10 Board suspended ceiling systemsPrimary
CAWS	K40/20 Board-suspended ceiling systems K40/135 Board-suspended ceiling system K11/885 Fire protection board K11/54 Fire protection board

SKU Code	CL SLUX-EI30-021S

Specification data - Board suspended ceiling systems

Classification data
Suspension grid	Framing: Steel C-Stud joists; U-Shaped channels. Guidance for specification option: Substrate: The surrounding construction must be concrete/masonry construction and capable of bearing the load of the ceiling membrane under fire conditions and must have a fire rating equal to or greater than the ceiling being installed. Primary channels: Minimum 150 x 47 x 1.2 mm steel C-Stud joists at maximum 610 mm centres. Edge channels: Minimum 150 x 53 x 1.2 mm U-Shaped channels fixed at maximum 500 mm centres to perimeter with minimum M8 x 85 mm suitable fixings by others.
Suspension grid fasteners	Fixing to primary channels: secure to C-Stud joists M16 bolt, nut, and washers. Brackets: connect joists to tracks via use of steel cleats. Guidance for specification option: Brackets: Minimum 6 mm thick, 160 x 75 x 130 mm (LxWxH) (1 per end connection). Bracket fixings: Bracket to perimeter (option 1): secure to end channel with minimum M16 × 30 mm countersunk bolt, nut, and washers (back-fixed). Bracket to perimeter (option 2): fix through end channel into substrate using Minimum M8 × 85 mm suitable fixings by others.
Insulation	None.
Linings	-
Inner layers	Facings underside outer layer: 12 mm PROMAT SUPALUX®. Guidance for specification option: Ceiling linings notes: Boards to be installed parallel to channels. Board layers to be staggered in both directions by minimum 300 mm.
Face layer	Facings topside outer layer: 12 mm PROMAT SUPALUX®. Guidance for specification option: Floor linings notes: Boards to be installed perpendicular to channels.
Fasteners	Outer layer fixings: minimum 42 mm self tapping drywall screws fixed at maximum 200 mm centres. Guidance for specification option: Ceiling linings fixing note: Screws positioned a minimum 10–12 mm from board edges and 30 mm from board corners.
Joint treatment	Cover strip (underside / topside): 100 mm wide 12 mm Promat SUPALUX® coverstrips behind transverse board joints. Guidance for specification option: Applied directly to board joints. Secured from outer layer with minimum 32 mm high thread drywall screws at maximum 200 mm centres.
Samples required	- Manufacturer guidance Consult manufacturer and insert requirements or omit.
System accessories	Floor fillet strip (underside / topside): one layer of 100 mm wide 12 mm thick Promat SUPALUX®. Guidance for specification option: Applied directly to joists. Fixed to all metal work with 25 mm self tapping drywall screws at maximum 200 mm centres.
Sealant	FSi Promat Pyrocoustic® Fire Resistant Sealant. Guidance for specification option: All boards abutting surrounding structure should be sealed using FSi Promat Pyrocoustic® Fire Resistant Sealant. All penetrations should use supporting constructions detailed in Promat literature unless superseded by specific test information. For combined, warrantied performance specify FSi fire-stopping products.
Fire performance	EI 30 in accordance with EN 13501-2.
Fire resistance	120 minutes integrity and 30 minutes insulation to EN 1364-2. Guidance for specification option: Direction of fire exposure: below only.
Finishes	Decorative. Guidance for specification option: Decorative finishes should be applied in accordance with Promat TDS 056 (https://www.promat.com/en-gb/construction/documentation/) and the Promat Passive Fire Protection Handbook (https://www.promat.com/en-gb/construction/tools-services/fire-protection-handbook/). Non-decorative. Guidance for specification option: None required to achieve quoted performances.
Size	Guidance for specification option: Maximum span: 3300 mm. Manufacturer guidance Consult manufacturer and insert requirements.
Thickness	174 mm. Manufacturer guidance Nominal.

Sustainability data

Country of material origin	China
Country of product manufacture	China Manufacturer guidance Applies to the bulk board material only. Other components are from other countries. Consult manufacturer for details.
Material	Calcium silicate
Recyclability	Gypsum, calcium silicate and metal components can be recycled depending on the segregation of all materials.
